2002-2006 Sprinter 2500 & 3500 Front Brake Kit-For 15" Wheels (BREMBO PADS) ***FREE USA SHIPPING***Sprinter 3500 & Sprinter 2500 with 15" wheels (check your tire & wheel size for confirmation)
Kit includes two standard Meyle rotors, two wear sensors & four Brembo ceramic brake pads and slide pin lubricant.
Ceramic pads produce less dust than semi-metallic pads.
THIS KIT WILL ONLY FIT MODELS ORIGINALLY EQUIPPED WITH 15 INCH WHEELS.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
2 to 3 Day Shipping to any US Zip Code included!
These kits are only for shipping to a US address.
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic. |
|
|
|
|
2002-2006 Sprinter 2500 & 3500 Front Brake Kit-For 15" Wheels (MEYLE PADS) ***FREE USA SHIPPING***Sprinter 2500 & 2500 originally equipped with 15" wheels
These are semi-metallic pads which are better at dissipating heat than ceramic pads.
The pads are made by Meyle or another European aftermarket supplier, depending upon what we have in stock.
Measure your rotor diameter, if in doubt, as these rotors are 276mm in diameter.
If you have 285mm diameter rotors, see the 16" wheel front brake kit, shown below
Kit includes two rotors, two wear sensors & four brake pads.
2 to 3 Day Shipping to any US Zip Code included! Not valid for shipping outside the USA.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
2002-2006 Sprinter 2500 & 3500 Front Brake Kit-For 16" Wheels (BREMBO Pads) ***FREE USA SHIPPING***Sprinter 3500 & Sprinter 2500 with 16" wheels (check your tire & wheel size for confirmation)
Kit includes two rotors, two wear sensors & four Brembo ceramic brake pads and slide pin lubricant.
Ceramic pads produce less dust than semi-metallic pads.
2 to 3 Day Shipping to any US Zip Code included!
These kits are only for shipping to a US address.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
2002-2006 Sprinter 2500 & 3500 Front Brake Kit-For 16" Wheels (MEYLE PADS) ***FREE USA SHIPPING***
Sprinter 2500 & 3500 originally equipped with 16" wheels (check your tire & wheel size for confirmation)
These are semi-metallic pads which are better at dissapating heat than ceramic pads.
The pads are made by Meyle or another European aftermarket supplier, depending upon what we have in stock.
Measure your rotor diameter, if in doubt, as these rotors are 285mm in diameter.
The rotors in this kit will not fit any Sprinter originally equipped with 15" wheels. If your vehicle was originall equipped with 15" wheels and you upgraded to 16" wheels, this kit will not fit The offset for the larger rotors is different than the offset for the smaller front rotors.
In other words......the pads, sensors and front calipers for both 15" and 16" wheel models are all identical. The rotors however, are different.
Kit includes two rotors, two wear sensors & four brake pads.
2 to 3 Day Shipping to any US Zip Code included! Not valid for shipping outside the USA.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
2002-2006 Sprinter 2500 Rear Brake Kit (BREMBO PADS) ***FREE USA SHIPPING***
Kit includes two rotors, two wear sensors & four Brembo ceramic brake pads and slide pin lubricant.
Ceramic pads produce less dust than semi-metallic pads.
2 to 3 Day Shipping to any US Zip Code included!
These kits are only for shipping to a US address.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
2002-2006 Sprinter 2500 Rear Brake Kit (PAGID PADS) ***FREE USA SHIPPING***
Sprinter 2500, fits all models with both 15" and 16" wheels.
These are semi-metallic pads which are better at dissipating heat than ceramic pads.
Rotors are made by Zimmerman. The pads are made by Pagid or another European aftermarket supplier, depending upon what we have in stock.
2 to 3 Day Shipping to any US Zip Code included!
These kits are only for shipping to a US address.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
2002-2006 Sprinter 3500 Rear Brake Kit (BREMBO PADS) ***FREE USA SHIPPING***Sprinter 3500
Kit includes two standard Meyle rotors, two wear sensors & four Brembo ceramic brake pads and slide pin lubricant.
Ceramic pads produce less dust than semi-metallic pads.
2 to 3 Day Shipping to any US Zip Code included! Not for delivery outside the USA
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
2002-2006 Sprinter 3500 Rear Brake Kit (MEYLE PADS) ***FREE USA SHIPPING***
Only for 3500 models
These are semi-metallic pads which are better at dissipating heat than ceramic pads.
The pads are made by Meyle or another European aftermarket supplier, depending upon what we have in stock.
2 to 3 Day shipping to most US Zip Codes included!
These kits are only for shipping to a US address.
BRAKE KITS ARE ONLY SHIPPED VIA US POSTAL SERVICE, NO FEDEX & NO UPS
No returns on brake kits. If you are unable to determine if you need new brakes, please consult a mechanic.
|
|
|
|
|
Brake Light Switch 4 Pin [with ESP] 2002-2006There are two different types of brake light switches, depending upon how your vehicle is equipped.
This one has a 4 pin spade connector and is only for vans with ESP (Electronic Stability Program).
The other 6 pin version is shown below.
|
|
|
|
|
Brake Light Switch 6 Pin [without ESP] 2002-2006
There are two different types of brake light switches, depending upon how your vehicle is equipped.
This one has a 6 pin spade connector and is only for vans without ESP (Electronic Stability Program).
The other 4 pin version is shown below.
|
|
|
|
|
Brake Pad Wear Sensor-Type A 2002-2006Front or Rear
For pads with narrow sensor groove and a small hole at the top of the pad
One sensor per wheel |
|
|
|
|
Brake Pad Wear Sensor-Type B 2002-2006Front or Rear
Only used for pads with wide sensor groove and no hole at the top of the pad
One sensor per wheel
IF YOU ARE PURCHASING OUR BRAKE PADS, DO NOT ORDER THESE SENSORS. ALL OF OUR PADS USE THE TYPE A SENSOR, SEE BELOW |
|
|
|
|
Brake Pedal Pad 2002-2006Brake pedal covering |
|
|
|
|
Brake Pressure Sensor 2002-2006
This is the identical Bosch part sold at a Mercedes or Dodge dealer.
aka: ESP SWITCH
LOCATED ON ABS HYDRAULIC PUMP, CHECK BOSCH PART# (0 265 005 303) ON ORIGINAL PART # TO VERIFY.
|
|
|
|
|
Brake Rotor Set Screw-Shouldered 2002-2006 2500Shouldered set screw for later brake rotors
Requires T-50 Torx driver to remove.
This is NOT the Phillips head screw type for the 2002 and some 2003 models
|
|
|
|
|
Brake Rotor Set Screw-Tapered 2002-2003Tapered set screw used on early 2500 & 3500 Models
This has a Phillips head |
|
|
|
|
Front ABS Speed Sensor 2002-2006
2 per vehicle, fits either left or right front wheel, 2500 or 3500.
Manufactured by Febi, a German aftermarket supplier of European automotive parts
|
|
|
|
|
Front ABS Speed Sensor 2002-2006 *SOLD OUT*
2 per vehicle, fits either left or right front wheel, 2500 or 3500.
Manufactured by Bosch, the OEM supplier to Mercedes.
|
|
|
|
|
Front Brake Rotor 2002-2006 w/15" WheelsAll 3500 Models and 2500 Models with 15inch wheels
Will not fit those models equipped with 16 inch wheels
|
|
|
|
|
Left Axle Bearing Cover 2002-2006Cover for left or driver's side wheel bearing
|
|
|
|
|
Left Rear Brake Backing Plate-2500 ONLY 2002-2006Only for 2500 models.
Left or driver's side rear axle.
|
|
|
|
|
Left Rear Brake Backing Plate-3500 ONLY 2002-2006Only for 3500 models.
Left or driver's side rear axle.
|
|
|
|
|
MEYLE Front Brake Pad Set-Bosch or Rear Wabco/Perrot 2002-2006A: All 2002-2006 Sprinter 2500 Front Pads, with either 15" or 16" wheels
B: All 2002-2006 Sprinter 3500 Front & Rear Pads (These pads will fit both Bosch and Wabco/Perrot calipers for the 3500 models)
All models regardless of body length
THESE PADS ARE A SEMI-METALLIC COMPOUND, MANUFACTURED BY MEYLE or another European aftermarket supplier, depending upon what we have in stock. With the current Covid pandemic, we have shortages, on occasion and have to purchase alternative products.
|
|
|
|
|
MEYLE Rear Brake Pad Set-ATE 2002-2006Sprinter 2500
118" Short Chassis
140" Medium Chassis
158" Long Chassis
The pads are made by Pagid, Bendix or another European supplier, depending upon what we have in stock.
With the current Covid pandemic, we have shortages, on occasion and have to purchase alternative products.
|
|
|
|
|
PEX Front Brake Pad Set- Ate Caliper Early 2002 OnlySprinter 2500 (early 2002 early short wheelbase models only)
118" Short chassis (There are few vehicles in North America that use these pads)
Only for Ate (Teves) front calipers
15" wheels on short chassis models
|
|
|
|
|
PEX Rear Brake Pad Set 2500 Bosch 2002Sprinter 2500 (Very early 2002 models ONLY)
118" short chassis
15 inch wheels
Bosch rear calipers, small version |
|
|
|
|
Rear ABS Speed Sensor 2002-2006
2 per vehicle, fits either left or right rear wheel. 2500 or 3500
Manufactured by Febi Bilstein a supplier to Mercedes and other manufacturers
|
|
|
|
|
Rear ABS Speed Sensor 2002-2006 *SOLD OUT*
2 per vehicle, fits either left or right rear wheel. 2500 or 3500
Manufactured by Febi Bilstein a supplier to Mercedes and other manufacturers
|
|
|
|
|
Rear ABS Tone Ring-2500 EARLY VERSION 2002-2006
Only for 2500 rear wheels. This is for the early version axle with a 62.5 mm diameter
THERE ARE TWO VERSIONS OF THESE. CHECK AXLE DIAMETER CAREFULLY, BEFORE ORDERING. SEE SECOND VERSION BELOW
The axle must be removed, in order to replace this item.
|
|
|
|
|
Rear ABS Tone Ring-2500 LATE VERSION 2002-2006Only for rear 2500 models This is for the late version axle with a 77.0 mm diameter
THERE ARE TWO VERSIONS OF THESE. CHECK AXLE DIAMETER CAREFULLY BEFORE ORDERING, SEE SECOND VERSION BELOW
The axle must be removed, in order to replace this item.
|
|
|
|
|
Rear Brake Rotor 2500 2002-2006For both 15" & 16" wheels
|
|
|
|
|
Rear Brake Rotor 3500 2002-2006For 3500 model only (dual rear axle)
|
|
|
|
|
Rear Wheel Lock Washer-3500 2002-2006Tapered lock washer for rear wheel studs on 3500 models ONLY
See stud ring below, also used on this vehicle.
|
|
|
|
|
Right Axle Bearing Cover 2002-2006Cover for right or passenger's side wheel bearing
|
|
|
|
|
Right Rear Brake Backing Plate-2500 ONLY 2002-2006Only for 2500 models.
Right or passenger's side rear axle
|
|
|
|
|
Right Rear Brake Backing Plate-3500 ONLY 2002-2006Only for 3500 models.
Right or passenger's side rear axle.
|
|
|
