140 991 00 55 X 10
10 PACK - Transmission Fill Pipe Cap Lock Pin 2002 & LATERPack of TEN at a discounted price.
Red plastic locking pin for black cap on transmission tube. |
|
|
|
|
140 270 10 98-PENTOSIN
2002 & 2018 Sprinter Automatic Transmission Service Kit - PENTOSIN FLUID
FOR ALL 5 CYLINDER & V6 SPRINTERS 2002-2018
Complete service kit with 8 liters of fully synthetic Pentosin Spec 236.14 (Supersedes MB Spec fluids 236.10 and 236.12) |
|
|
|
|
124 990 22 01
2002-2006 Torque Converter BoltThis bolt connects the torque converter and the flywheel assemblies together. There are 6 required per vehicle. |
|
|
|
|
140 270 11 61-MB-KIT
2002-2018 Sprinter Automatic Transmission Conductor Plate Kit
FOR ALL 5 CYLINDER & V6 SPRINTERS 2002-2018
Complete Service Kit Includes:
8 x 1 Liter of Genuine Mercedes Benz Fluid
1 x Conductor plate (ZF OEM)
1 x Transmission oil filter kit (Febi Bilstein)
1 x Transmission pan gasket (Febi Bilstein)
1 x Adapter plug housing (Kostal OEM)
1 x Transmission dip stick
2 x Drain plug seal rings (Elring) |
|
|
|
|
140 270 11 61-FUCHS-KIT
2002-2018 Sprinter Automatic Transmission Conductor Plate Kit
FOR ALL 5 CYLINDER & V6 SPRINTERS 2002-2018
Kit Includes:
Complete service kit with 8 liters of Fuchs Fluid
1 x Transmission oil filter kit (Febi Bilstein)
1 x Transmission pan gasket (Febi Bilstein)
2 x Drain plug washers
1 x Conductor plate - (German Aftermarket)
1 x Adapter plug housing - (Kostal OEM)
1 x Transmission dip stick |
|
|
|
|
140 270 10 98-FUCHS
2002-2018 Sprinter Automatic Transmission Service Kit - FUCHS OEM FLUID
FOR ALL 5 CYLINDER & V6 SPRINTERS 2002-2018
Complete service kit with 8 liters of Spec 236.14 Fluid in Fuchs containers (Supersedes MB Spec fluids 236.10 and 236.12)
This fluid is manufactured by Fuchs,
an OEM supplier for factory fill fluids on the assembly line.
|
|
|
|
|
140 270 10 98-MB
2002-2018 Sprinter Automatic Transmission Service Kit - Mercedes Benz Fluid
For ALL 5 Cylinder& V6 Sprinters 2002-2018
Complete service kit with of 8 liters of Spec 236.14 Fluid in Mercedes Benz containers (Supersedes 236.10 and 236.12 fluids).
|
|
|
|
|
140 990 45 01
2002-2023 Transmission Pump BoltThere are 7 required, fixes transmission pump to transmission. |
|
|
|
|
002 542 66 18
Acceleration Sensor 2002 & LATERaka Yaw Sensor or Lateral Accelerometer Sensor
Traction Control System
Affects ABS and stability control systems |
|
|
|
|
163 271 00 80
Bellhousing Plug-Rectangular 2002-2006Torque Converter Access Port
There are two of these plugs at the bottom of the bell housing
Compare to the oval plastic plug shown below.
|
|
|
|
|
722 270 01 97
Front Transmission Pump 2002 & LATER
Surrounds A/T front input shaft inside the bell housing
Both the O ring and input shaft seal are furnished with the pump
|
|
|
|
|
016 997 14 48
Front Transmission Pump O-Ring 2002 & LATERSurrounds the outside perimeter of the front transmission pump |
|
|
|
|
018 997 04 47
Front Transmission Pump Seal 2002 & LATER
AKA Torque Converter seal
Located in center of front transmission pump.
There is also a large diameter o-ring at the circumference of the front pump, See Below.
|
|
|
|
|
001 989 68 03-MB
Genuine Mercedes - 1L Transmission Fluid - 2002-2018 5cyl & v6 models - 236.14
1 Liter Container - Genuine Mercedes
MB Spec 236.14 (Supersedes the 236.12) on the Mercedes label
This fluid is specified by Mercedes for use in your Sprinter A/T. |
|
|
|
|
646 050 02 03
Genuine Mercedes - Crankshaft Gear 2002-2006
This is the crankshaft gear that is attached to the timing chains.
|
|
|
|
|
001 989 68 03-FUCHS-1LTR
OEM FUCHS - 1L Transmission Fluid - 2002-2018 5 Cyl & V6 Models - ATF4134
1 Liter Container - MB Spec 236.14 under the Fuchs label
This is the newest fluid specified by Mercedes for use in your Sprinter A/T.
This fluid is manufactured by Fuchs, an OEM supplier for factory fill fluids on the assembly line. They are a supplier of differential and transmission fluid, as well as engine oil. |
|
|
|
|
001 989 68 03-FUCHS-5LTR
OEM FUCHS - 5L Transmission Fluid - 2002-2018 5 Cyl & V6 Models - ATF4134
5 Liter Container - MB Spec 236.14 under the Fuchs label
This is the newest fluid specified by Mercedes for use in your Sprinter A/T.
This fluid is manufactured by Fuchs, an OEM supplier for factory fill fluids on the assembly line. They are a supplier of differential and transmission fluid, as well as engine oil.
|
|
|
|
|
140 270 11 61-KOSTAL
OEM Transmission Conductor Plate 2002 & LATER
For all 5 CYL and V6 engine models ONLY, both gas and diesel - NOT for any 4 CYL engine models.
This part is manufactured by ZF, the OEM supplier to Mercedes. This is the exact same part as sold at a Mercedes dealership.
|
|
|
|
|
140 270 11 61-ZF
OEM Transmission Conductor Plate 2002 & LATER
For all 5 CYL and V6 engine models ONLY, both gas and diesel - NOT for any 4 CYL engine models.
This part is manufactured by ZF, the OEM supplier to Mercedes. This is the exact same part as sold at a Mercedes dealership.
Located above the valve body in the transmission. Houses six solenoids and the adapter plug housing and also houses the dipstick tip socket. This part comprises the uppermost portion of the valve body.
The speed sensor located on this plate (140 540 36 17) is an integral part of this unit and is NOT available as separate part.
This part interfaces with the adapter plug housing, shown below.... |
|
|
|
|
001 989 68 03-PENTOSIN-1LTR
PENTOSIN - 1L Transmission Fluid - 2002-2018 5 Cyl & V6 Models - ATF134
1 Liter Container - Pentosin OE approval on Mercedes spec. 236.14 (Supersedes 236.10 and 236.12)
This is the newest fluid specified by Mercedes for use in your Sprinter A/T.
This fluid is manufactured by Pentosin and is full synthetic. Pentosin ATF 134 is an ultra high-performance automatic transmission fluid developed to improve shifting comfort for the new generation of Mercedes-Benz 5-Speed 722.6.
|
|
|
|
|
001 989 68 03-PENTOSIN-5LTR
PENTOSIN - 5L Transmission Fluid - 2002-2018 5 Cyl & V6 Models - ATF134
5 Liter Container - MB Spec 236.14 under the Pentosin label
This is the newest fluid specified by Mercedes for use in your Sprinter A/T.
This fluid is manufactured by Pentosin and is full synthetic. Pentosin ATF 134 is an ultra high-performance automatic transmission fluid developed to improve shifting comfort for the new generation of Mercedes-Benz 5-Speed 722.6.
|
|
|
|
|
901 260 13 51
Shift Selector Cable 2002-2006This is the longer of the two cables in this area
|
|
|
|
|
901 260 19 09
Shifter Control Assembly WITHOUT ESP 2002-2006
Only for those models WITHOUT ESP (Electronic Stability Program)
If you are not certain, check your brake light switch above the brake pedal.
4-Pin connector is WITH ESP
6-Pin connector is WITHOUT ESP
See other version shown below....
|
|
|
|
|
901 260 29 09
Shifter Control Assembly-WITH ESP 2002-2006
Only for those models WITH ESP (Electronic Stability Program)
If you are not certain, check your brake light switch above the brake pedal and count the number of pins on the electrical connector.
4-Pin connector is WITH ESP
6-Pin connector is WITHOUT ESP
See other version shown below......
|
|
|
|
|
016 997 34 48
Speed Sensor/ Reaction Valve O Ring-Seal 2002 & LATERCommon source of transmission fluid leakage.
Located at the top rear of the transmission case.
|
|
|
|
|
140 589 15 21 00
Sprinter Transmission Service Dipstick-5 CYL & V6 ModelsService tool for checking transmission fluid level in all Sprinter transmissions
Includes instruction sheet
NOTE: The dipstick is longer than the dipstick tube in most cases, as it is used on multiple models.
|
|
|
|
|
MC18S
Torque Converter 2002-2006
For 722.6 transmissions - 5 cylinder engine only.
Send your used unit back for a $100 refund.
Remanufactured by an American company.
|
|
|
|
|
220 271 00 68
Transmision Pan Clamp-Version A SPRINTER & METRIS 2002 & LATER
These clamps work in conjunction with the six transmission pan bolts to secure the pan to the bottom of the transmission.
A quantity of 5 clamps are required and 1 of the other version clamp as shown below. |
|
|
|
|
220 271 02 68
Transmision Pan Clamp-Version B 2002 & LATERThese clamps work in conjunction with the six transmission pan bolts to secure the pan to the bottom of the transmission.
Quantity of 1 of this clamp is required and 5 of the other version clamp, shown below. |
|
|
|
|
203 540 02 53
Transmission Adapter Plug Housing 2002 & LATER
A very common source of A/T fluid leaks. This is the third and most recent revision of this part. This part is manufactured by the OEM supplier to Mercedes.
This part interfaces with the OEM Conductor Plate, shown below....
Here is a link to a You Tube video of the replacement procedure for this problematic part. It was done on a Mercedes SLK but, this unit is used on many automatic transmissions in series 722.6 https://youtu.be/QvwxeCy8xRQ
|
|
|
|
|
140 270 11 61-AFT
Transmission Conductor Plate 2002 & LATER
For all 5 CYL and V6 engine models ONLY, both gas and diesel
NOT for any 4 CYL engine models
This part interfaces with the adapter plug housing, shown below....
Located above the valve body in the transmission.
Houses six solenoids and the adapter plug housing and also houses the dipstick tip socket.
This part comprises the uppermost portion of the valve body.
The speed sensor located on this plate (140 540 36 17) is an integral part of this unit and is NOT available as separate part.
|
|
|
|
|
901 271 00 96
Transmission Cooler Hose/Pipe-Feed Line 2002-2006
This is the supply hose which consists mostly of metal piping with a hose swaged onto one end.
THIS IS #1 ON THE DODGE PARTS DIAGRAM
FOR IDENTIFICATION PURPOSES, THE LENGTH OF THE RUBBER HOSE IS 400mm OR APPROX 15.75 INCHES
IF THERE IS ANY QUESTION, EXAMINE YOUR EXISTING HOSE CLOSELY BEFORE ORDERING. THE MERCEDES PART NUMBER IS STAMPED ON THE FERRULE.
|
|
|
|
|
901 271 02 96
Transmission Cooler Hose/Pipe-Pressure Line 2002-2006
This is the feed hose which consists mostly of metal piping with a hose swaged onto one one end.
THIS IS #2 ON THE DODGE PARTS DIAGRAM
FOR IDENTIFICATION PURPOSES, THE LENGTH OF THE RUBBER HOSE IS 215mm OR APPROX 8.50 INCHES
IF THERE IS ANY QUESTION, EXAMINE YOUR EXISTING HOSE CLOSELY BEFORE ORDERING. THE MERCEDES PART NUMBER IS STAMPED ON THE FERRULE.
|
|
|
|
|
901 271 01 96
Transmission Cooler Hose/Pipe-Supply Line 2002-2006
This is the supply hose which consists mostly of metal piping with a hose swaged onto one end.
THIS IS #9 ON THE DODGE PARTS DIAGRAM
FOR IDENTIFICATION PURPOSES, THE LENGTH OF THE RUBBER HOSE IS 420mm OR APPROX 16.5 INCHES
IF THERE IS ANY QUESTION, EXAMINE YOUR EXISTING HOSE CLOSELY BEFORE ORDERING. THE MERCEDES PART NUMBER IS STAMPED ON THE FERRULE.
|
|
|
|
|
220 997 16 52
Transmission Cooler Hose-Return Line 2002-2006This is the return hose located on the upper right side of the radiator. This is the shorter one of the two and is comprised mostly rubber hose with a small 90 degree pipe fitting on the one end. IT IS #13 ON THE DODGE PARTS DIAGRAM.
It links two metal pipes together.
EXAMINE AND COMPARE TO THE OTHER SIMILAR HOSES BELOW, PRIOR TO ORDERING
|
|
|
|
|
901 500 03 72
Transmission Cooler Pipe-Return Line 2002-2006Metal pipe linking cooler to flex hose
This is #14 in the Dodge illustration. It links to part # 13, see below.
|
|
|
|
|
901 500 02 72
Transmission Cooler Pipe-Supply Line 2002-2006Metal pipe linking cooler to flex hose
This is #10 in the Dodge illustration.
It links to part # 9, see below.
|
|
|
|
|
007603-010100
Transmission Drain Plug Seal Ring-Torque Converter 2002-2006 & A/T Oil Pan 2002-2018Fits Torque Converter drain plug 2002-2006
Fits A/T Sump Pan drain plug 2002-2018 V6 models only.
Manufactured by Elring. One of several OEM gasket suppliers to Mercedes.
|
|
|
|
|
140 270 00 91
Transmission Fill Pipe Cap 2002 & LATER
Black plastic cap for A/T fill tube
Also need red plastic locking pin.
|
|
|
|
|
140 991 00 55
Transmission Fill Pipe Cap Lock Pin 2002 & LATERRed plastic locking pin for black cap on transmission tube
|
|
|
|
|
140 270 00 98
Transmission Filter Kit 2002-2018
Contains the filter element, pan gasket, two seal rings for M8 drain plugs, and red lock pin for automatic transmissions.
For all 5 CYL models and 3.0L V6 engine
|
|
|
|
|
140 270 65 00
Transmission Gasket Set 2002 & LATERSeal set for transmission overhaul |
|
|
|
|
000 270 25 00
Transmission Gasket Set 2014-2016 SPRINTER & METRIS 4 CYL MODELSComplete gasket set for the A/T
|
|
|
|
|
901 242 15 13
Transmission Mount 2002-2006
One Required per Vehicle
|
|
|
|
|
639 272 01 45
Transmission Output Flange 2002-2006Bolt holes, measured diagonally are 101.6 mm, center to center.
|
|
|
|
|
015 997 12 46
Transmission Output Shaft Seal - REAR 2002 & LATER
Located in rear A/T tail shaft housing, behind the output flange.
Manufactured by Corteco, the OEM supplier to Mercedes Benz.
|
|
|
|
|
140 270 08 12
Transmission Pan 2002 & LATERIncludes drain plug and drain plug seal ring.
Fits all transmissions for both 5 cylinder and V6 engines
NOT for any 4CYL engine models
|
|
|
|
|
000000-000884
Transmission Pan Drain Plug M10-Torque Converter 2002-2006 & A/T Oil Pan 2002-2018Fits Torque Converter drain plug 2002-Mid 2006 (Late 2006 and thereafter uses a smaller diameter M8 torque converter drain plug, see below)
Fits A/T Sump Pan drain plug 2002-2018 M10 Plug size, uses a 5 mm allen wrench
|
|
|
|
|
901 267 09 64
Transmission Parking Interlock Cable 2002-2006This is the shorter of the two cables in this area
|
|
|
|
|
203 270 00 89
Transmission Solenoid - Type C 2002-2016
There are a mix of different
solenoids. To determine which one you need look at the last four digits
of the part number on the solenoid in question. |
|
|
|
|
