Ambient Temperature Sensor SPRINTER & METRIS 2007 & LATERLocated behind front bumper. Although very small and seemingly insignificant, this is a critical sensor, as it signals ambient/outside air temperature to the engine control module.
|
|
|
|
|
Antenna Assembly-MOBILE PHONE VERSION 2014-2018
Complete assembly.
THIS ANTENNA HAS A THREE WIRE CONNECTION, IF YOU HAVE A TWO WIRE CONNECTION, SEE BELOW
Antenna mast is also available as a separate unit, see below
|
|
|
|
|
Battery Isolation Relay 2002-2018Relay used in conjunction with secondary or auxiliary battery.
This relay will isolate or disconnect the auxiliary battery from the main battery, when the engine is not running and charging the batteries.
MB Part # on relay is 002 542 40 19
|
|
|
|
|
Brake Light Switch 2007 & LATER4 pin spade connector |
|
|
|
|
Control Module-Power & Heated Mirrors 2007-2010
|
|
|
|
|
Coolant Level Sensor 2007-2018Fits Gas & Diesel V6 engine models
Located in bottom of Coolant Expansion Tank. |
|
|
|
|
Cruise Control Switch 2007 & LATERAdjacent to turn signal and wiper switch on left side of steering column
|
|
|
|
|
Distance Control / Collision Assist Module
For vehicles with Distance control / Collision assist.
Replaces old part # 906-900-09-02
New part # is 906 900 67 02
|
|
|
|
|
Evaporator Temperature Sensor 2002-2018Located in evaporator case of all Sprinters and Metris
|
|
|
|
|
Flasher Module Relay 2007-2013Turn signal & emergency flasher relay
|
|
|
|
|
Front Door Contact Switch 2002-2018Found at both front doors and side sliding door. Used for overhead dome lights.
|
|
|
|
|
Headlight Switch WITH BOTH FOG LIGHTS & RAIN SENSOR 2007-2018There are four different headlight switches for this Sprinter
This switch is only for models WITH fog lights AND rain sensor.
For models with NO fog lights and NO rain sensor, see below.
For models WITH fog lights alone and NO rain sensor, see below.
For models WITH rain sensor alone and NO fog lights, see below.
Please choose carefully before ordering, as electrical parts are NOT returnable.
The switch choice is contingent upon how your van is equipped, with fog
lights, or with rain sensor or with both rain sensor and fog lights.
See
other three versions below.
|
|
|
|
|
Headlight Switch WITH FOG LIGHTS ALONE 2007-2018There are four different headlight switches for this Sprinter
This switch is only for models WITH fog lights and NO rain sensor
For models with NO rain sensor and NO foglights, see below.
For models WITH both rain sensor AND fog lights, see below. For models WITH rain sensor alone, and NO fog lights, see below.
Please choose carefully before ordering, as electrical parts are NOT returnable.
The switch choice is contingent upon how your van is equipped, with fog lights, or with rain sensor or with both rain sensor and fog lights. See
other three versions below.
|
|
|
|
|
Headlight Switch WITH RAIN SENSOR ALONE 2007-2018There are four different headlight switches for this Sprinter
This switch is only for models WITH rain sensor alone and NO fog lights.
For models with NO fog lights and NO rain sensor, see below.
For models WITH rain sensor AND fog lights, see below.
For models WITH fog lights alone and NO rain sensor, see below.
Please choose carefully before ordering, as electrical parts are NOT returnable.
The switch choice is contingent upon how your van is equipped, with fog
lights, or with rain sensor or with both rain sensor and fog lights.
See
other three versions below.
|
|
|
|
|
Headlight Switch-BASIC WITH NO EXTRAS 2007-2018
There are four different headlight switches for this Sprinter
This switch is only for models with NO fog lights and NO rain sensor.
For models WITH fog lights alone and NO rain sensor, see below.
For models WITH rain sensor alone and NO fog lights, see below.
For models with BOTH fog lights and rain sensor, see below.
Please choose carefully before ordering, as electrical parts are NOT returnable.
The switch choice is contingent upon how your van is equipped, with fog
lights, or with rain sensor or with both rain sensor and fog lights.
See
other three versions below.
|
|
|
|
|
Horn 2002-2013Supersedes the original horn, which has been discontinued by Mercedes.
The new horn requires a short wiring harness to adapt this to your vehicle and must be spliced at the time of installation (see harness below)
To install: Plug the new harness into horn, and cut the larger plug off the opposite end. Then, cut the plug off the end of the vehicle wire harness and slice the two wires together, using electrical tape to insulate the connections. (Despite the bizarre sound of these instructions, they are straight from Mercedes Benz)
|
|
|
|
|
Horn Wiring Harness 2002-2013Required to adapt new replacement horn (old horn has been discontinued)
To Install: Plug the new harness into horn, and cut
the larger plug off the opposite end. Then, cut the plug off the end
of the vehicle wire harness and splice the two wires together, using electrical tape to insulate the connections.
|
|
|
|
|
Left Window Switch Assembly-W/O Mirror Control 2007-2018Left driver door
Standard window switch assembly for models WITHOUT power mirrors. |
|
|
|
|
Left Window Switch Assembly-WITH Mirror Control 2007-2018
Left driver door window switch assembly.
Only for models equipped WITH power mirrors.
Manufactured by Febi-Bilstein, an OEM supplier to Mercedes.
|
|
|
|
|
Multi-Function Relay #1 (5 pin) 2002-2018
RELAY COULD BE LABELED AS PART 003 542 02 19 OR 004 545 29 05
5 pin relay, body of relay is half-size, not a cube, and may be either black or grey.
Multiple uses, including Daytime Running Lights
Common replacement item and found in various areas of the vehicle.
There are approximately ten of these relays used in multiple locations on all Sprinter models.
Carrying a few spares is always a good idea.
|
|
|
|
|
Multi-Function Relay #2 (5 pin) SPRINTER & METRIS 2002-2018Cube shaped 5 pin relay. Used in the starter relay circuit, and for other circuits, as well.
Located under driver seat
MB part # on old relay could be 004 545 79 05, 002 542 14 19, 002 542 96 19, 003 542 10 19, 002 542 89 19, 000 982 25 23, 000 982 81 23
|
|
|
|
|
Multi-Function Relay #3 (4 pin) 2002-2018Cube shaped 4 pin relay
Located under driver seat |
|
|
|
|
Multi-Function Relay #5 2002 & LATERMercedes part # on unit could be 004 545 38 05 or 004 545 79 05
|
|
|
|
|
Multi-Function Relay (4 pin) SPRINTER & METRIS 2002-2018
Located under driver seat blue in color.
|
|
|
|
|
Positive Battery Cable/Harness- 2014-2016 4CYL Diesel
Has 3 connections and the jump start terminal.
If you have had continuing sluggish starts and other electrical problems and you are certain that you have a strong alternator, generating an output of 14V, you may want to look closely at your positive battery cable. This is often a common area of electrical trouble, especially for internal corrosion. |
|
|
|
|
Positive Battery Cable/Harness-180 AMP 2007 & LATER 3.0L V6 Diesel
ONLY FOR MODELS WITH 180 AMP ALTERNATOR
If in doubt, look at the back of the black
plastic back cover on your alternator. It will be marked either 180A
or 220A.
If you have had continuing sluggish starts and other electrical problems and you are certain that you have a strong alternator, generating an output of 14V, you may want to look closely at your positive battery cable/harness, especially for internal corrosion on the copper braiding.
This can be a common occurrence in older cables.
This is often a common area of electrical trouble and is commonly referred to as the infamous "Y cable"
This is the fourth revision of this cable by Mercedes. All three of the previous units have been discontinued and should no longer be installed.
This cable is the most current revision. 906 440 14 09, 906 440 35 38 and 906 440 81 55, are all obsolete.
|
|
|
|
|
Positive Battery Cable/Harness-220 AMP 2007 & LATER 3.0L V6 Diesel
ONLY FOR MODELS WITH 220 AMP ALTERNATOR
If you have had continuing sluggish starts and other electrical problems and you are certain that you have a strong alternator, generating an output of 14V, you may want to look closely at your positive battery cable. This is often a common area of electrical trouble, especially for internal corrosion.
This is often a common area of
electrical trouble and is commonly referred to as the infamous "Y
cable"
The
220 Amp alternators are used on those models with a secondary A/C
compressor (Roof-mounted A/C units).
If in doubt, look at the black
plastic backing plate on the alternator. It will be marked either 180A
or 220A.
This
is the third revision of this cable/harness by Mercedes. Both of the
previous units have been discontinued, and should no longer be
installed. This cable is the most current revision.906 440 96 37 and 906 440 84 55, are both obsolete
|
|
|
|
|
Positive Battery Cable-220 AMP 3.5L V6 Gas Engine 2007-2008ONLY FOR GAS ENGINE MODELS WITH 220 AMP ALTERNATOR
If you have had continuing sluggish starts and other electrical problems and you are certain that you have a strong alternator, generating an output of 14V, you may look closely at your positive battery cable. This is often a common area of electrical trouble.
This is the third revision of this cable by Mercedes. All three of the previous units have been discontinued.
|
|
|
|
|
Rear Cargo Door Contact Switch 2002-2018Found at the rear door. For overhead dome light.
|
|
|
|
|
Right Window Switch Assembly 2007-2018Right passenger door window switch
|
|
|
|
|
Shifter Control Assembly 2007-2018
The Neutral Safety Switch is part of this assembly and is not available as a separate unit.
THIS UNIT IS NOT PLUG AND PLAY. THE VEHICLE'S ECM MUST BE FLASHED (PROGRAMMED)
USING THE CORRECT PROGRAMMING DEVICE, AT THE TIME OF INSTALLATION.
|
|
|
|
|
Steering Wheel Lock 2007-2018Steering wheel lock also known as EVL or ESL. This device locks the steering wheel for anti theft purposes. Found on steering column.
|
|
|
|
|
Switch Hole Cover 2007-2018Covers empty hole in instrument panel for those openings where no switch is used.
|
|
|
|
|
Throttle Pedal Actuator-METRIS & SPRINTER 2007 & LATERComplete assembly, with pedal.
|
|
|
|
|
Tire Pressure Sensor-Original Type 2007-2012One sensor is located at each wheel, including the spare tire.
For all vehicles equipped with TPMS
This part is manufactured by VDO (315MHz), the OEM supplier to Mercedes.
It is identical to those sold at a franchise Mercedes, Dodge or Freightliner dealer.
We also offer a VDO replacement version of this sensor, see below
|
|
|
|
|
Tire Pressure Sensor-Original Type 2013-2018One sensor is located at each wheel, including the spare tire.
For all vehicles equipped with TPMS
This part is manufactured by Schrader (433 MHz), the OEM supplier to Mercedes.
It is identical to those sold at a franchise Mercedes, Dodge or Freightliner dealer.
|
|
|
|
|
Tire Pressure Sensor-Replacement Type 2007-2012One sensor is located at each wheel, including the spare tire.
For all vehicles equipped with TPMS
This part is manufactured by VDO (315MHz) , the OEM supplier to Mercedes.
It is a replacement unit and NOT the same as those sold at a franchise Mercedes, Dodge or Freightliner dealer.
The frequency is identical and it will perform perfectly.
ORIGINAL UNIT IS ALSO AVAILABLE, SEE BELOW
|
|
|
|
|
Turn Signal Combi Switch W/O Rear Wiper 2007 & LATERTurn signal and wiper switch on left side of steering column.
This switch is ONLY for models without wipers on the rear cargo doors.
|
|
|
|
|
Turn Signal Combi Switch With Rear Wiper 2007 & LATERTurn signal and wiper switch on left side of steering column.
This switch is ONLY for models with wipers on the REAR CARGO DOORS, in addition to the front wipers.
|
|
|
|
|
Washer Level Sensor 2007-2018Washer reservoir level sensor in side of tank. See grommet below
|
|
|
|
|
Wiring Hub / ConnectorThese commonly will cause a "Can Bus" error.
Found throughout the vehicle, Mercedes calls it a "DISTRIBUTOR". We ordered these at the request of a customer. Simply find the part number on old part to verify this is the correct item you need. Mercedes# 004 546 82 40
|
|
|
|
|
Wiring Hub / ConnectorThese commonly will cause a "Can Bus" error.
Found throughout the vehicle, Mercedes calls it a "DISTRIBUTOR".
We ordered these at the request of a customer. Simply find the part
number on old part to verify this is the correct item you need.
Mercedes# 004 546 749 40
|
|
|
|
|
Wiring Hub / Connector
These commonly will cause a "Can Bus" error.
Found throughout the vehicle, Mercedes calls it a "DISTRIBUTOR".
We ordered these at the request of a customer. Simply find the part
number on old part to verify this is the correct item you need.
Has 5 x 2-pin plug connections and 1 x 3-pin plug connection
Mercedes part 005 546 10 40
|
|
|
