007 542 13 18
Ambient Temperature Sensor SPRINTER & METRIS 2007 & LATER
Located behind front bumper. Although very small and seemingly insignificant, this is a critical sensor, as it signals ambient/outside air temperature to the engine control module.
|
|
|
|
|
906 905 65 00
Antenna Assembly-MOBILE PHONE VERSION 2014-2018
Complete assembly.
THIS ANTENNA HAS A THREE WIRE CONNECTION, IF YOU HAVE A TWO WIRE CONNECTION, SEE BELOW
Antenna mast is also available as a separate unit, see below
|
|
|
|
|
906 905 98 00
Back Up Camera - LARGE VERSION 2014-2018
Complete assembly, with housing.
This is the larger of the two different cameras.
The housing is approximately 9 1/2 inches long.
The other camera model, shown below, is much smaller (6 inches long) in size and shape.
|
|
|
|
|
906 905 99 00
Back Up Camera - SMALL VERSION 2014-2018
*Discontinued by Mercedes - No Longer Available after Stock is Depleted*
Complete assembly, with housing.
This is the smaller of the two different cameras.
The camera housing is approximately 6 inches long
The other version camera, shown below, is much larger in size (9 1/2 inches long) and has a different overall shape.
|
|
|
|
|
002 542 40 19
Battery Isolation Relay 2002-2018
Relay used in conjunction with secondary or auxiliary battery.
This relay will isolate or disconnect the auxiliary battery from the main battery when the engine is not running and charging the batteries.
MB Part # on relay is 002 542 40 19
|
|
|
|
|
001 545 67 09-MB
Brake Light Switch - Genuine Mercedes 2007 & LATER
4 pin spade connector |
|
|
|
|
001 545 67 09-AFT
Brake Light Switch 2007 & LATER
4 pin spade connector |
|
|
|
|
906 820 56 26
Control Module-Power & Heated Mirrors 2007-2010
|
|
|
|
|
203 870 09 51
Coolant Level Sensor 2007-2018
Fits Gas & Diesel V6 engine models.
Located in bottom of Coolant Expansion Tank.
|
|
|
|
|
906 545 04 24
Cruise Control Switch 2007 & LATER
Adjacent to turn signal and wiper switch on left side of steering column
|
|
|
|
|
906 900 67 02
Distance Control / Collision Assist Module
For vehicles with Distance control / Collision assist.
Replaces old part # 906-900-09-02
New part # is 906 900 67 02
|
|
|
|
|
220 830 07 72-FEBI
Evaporator Temperature Sensor 2002-2024 FEBI
Located in evaporator case of all Sprinters and Metris. |
|
|
|
|
220 830 07 72-OEM
Evaporator Temperature Sensor 2002-2024 OEM
Located in evaporator case of all Sprinters and Metris.
Mahle Behr is the OEM Supplier to Mercedes for this part. |
|
|
|
|
035 545 51 32
Flasher Module Relay 2007-2013Turn signal & emergency flasher relay
|
|
|
|
|
005 820 81 10
Front Door Contact Switch 2002-2018
Found at both front doors and side sliding door.
Used for overhead dome lights.
|
|
|
|
|
906 545 12 13-MB
Genuine Mercedes - Left Window Switch Assembly-WITH Mirror Control 2007-2018
Left driver door window switch assembly.
Only for models equipped WITH power mirrors.
Manufactured by Febi-Bilstein, an OEM supplier to Mercedes.
|
|
|
|
|
906 545 19 13-MB
Genuine Mercedes - Right Window Switch Assembly 2007-2018
Right passenger door window switch
|
|
|
|
|
906 905 27 01
Headlight Switch WITH BOTH FOG LIGHTS & RAIN SENSOR 2007-2018
There are FOUR different headlight switches for this Sprinter. This switch is only for models WITH fog lights AND rain sensor.
For models with NO fog lights and NO rain sensor, Click Here.
For models WITH fog lights alone and NO rain sensor, Click Here.
For models WITH rain sensor alone and NO fog lights, Click Here.
Please choose carefully before ordering, as electrical parts are NOT returnable. The switch choice is contingent upon how your van is equipped, with fog lights / with rain sensor / with both rain sensor and fog lights. |
|
|
|
|
906 545 03 04
Headlight Switch WITH FOG LIGHTS ALONE 2007-2018
There are four different headlight switches for this Sprinter.
This switch is only for models WITH fog lights and NO rain sensor.
For models with NO rain sensor and NO fog lights, see below.
For models WITH both rain sensor AND fog lights, see below. For models WITH rain sensor alone, and NO fog lights, see below.
Please choose carefully before ordering, as electrical parts are NOT returnable. The switch choice is contingent upon how your van is equipped, with fog lights, or with rain sensor or with both rain sensor and fog lights. See
other three versions below.
|
|
|
|
|
906 545 02 04
Headlight Switch WITH RAIN SENSOR ALONE 2007-2018
There are four different headlight switches for this Sprinter. This switch is only for models WITH rain sensor alone and NO fog lights.
For models with NO fog lights and NO rain sensor, see below.
For models WITH rain sensor AND fog lights, see below.
For models WITH fog lights alone and NO rain sensor, see below.
The switch choice is contingent upon how your van is equipped, with fog lights, or with rain sensor or with both rain sensor and fog lights. See other three versions below. |
|
|
|
|
906 905 24 01
Headlight Switch-BASIC WITH NO EXTRAS 2007-2018
There are four different headlight switches for this Sprinter
This switch is only for models with NO fog lights and NO rain sensor.
For models WITH fog lights alone and NO rain sensor, see below.
For models WITH rain sensor alone and NO fog lights, see below.
For models with BOTH fog lights and rain sensor, see below.
Please choose carefully before ordering, as electrical parts are NOT returnable. The switch choice is contingent upon how your van is equipped, with fog
lights, or with rain sensor or with both rain sensor and fog lights.
See
other three versions below.
|
|
|
|
|
639 540 00 76
Horn 2002-2013Supersedes the original horn, which has been discontinued by Mercedes.
The new horn requires a short wiring harness to adapt this to your vehicle and must be spliced at the time of installation (see harness below)
To install: Plug the new harness into horn, and cut the larger plug off the opposite end. Then, cut the plug off the end of the vehicle wire harness and slice the two wires together, using electrical tape to insulate the connections. (Despite the bizarre sound of these instructions, they are straight from Mercedes Benz)
|
|
|
|
|
639 440 66 13
Horn Wiring Harness 2002-2013
Required to adapt new replacement horn (old horn has been discontinued)
To Install: Plug the new harness into horn, and cut
the larger plug off the opposite end. Then, cut the plug off the end
of the vehicle wire harness and splice the two wires together, using electrical tape to insulate the connections.
|
|
|
|
|
906 545 12 13-FEBI
Left Window Switch Assembly - WITH Mirror Control 2007-2018
Left Driver door window switch assembly.
Only for models equipped WITH power mirrors.
Manufactured by Febi-Bilstein, an OEM supplier to Mercedes.
|
|
|
|
|
906 545 10 13-MB
Left Window Switch Assembly - without Mirror Control 2007-2018
Left Driver door
Standard window switch assembly for models WITHOUT power mirrors.
|
|
|
|
|
906 545 10 13-AFT
Left Window Switch Assembly - without Mirror Control 2007-2018
Left Driver door
Standard window switch assembly for models WITHOUT power mirrors.
|
|
|
|
|
004 545 29 05
Multi-Function Relay #1 (5 pin) 2002-2018
RELAY COULD BE LABELED AS PART # 003 542 02 19 or # 004 545 29 05
5 pin relay, body of relay is half-size, not a cube, and may be either black or grey.
Multiple uses, including Daytime Running Lights. Common replacement item and found in various areas of the vehicle. There are approximately ten of these relays used in multiple locations on all Sprinter models. |
|
|
|
|
002 542 74 19
Multi-Function Relay #2 (5 pin) SPRINTER & METRIS 2002-2018
Cube shaped 5 pin relay. Used in the starter relay circuit, and for other circuits, as well.
Located under driver seat.
MB part number on old relay could be:
004 545 79 05
002 542 14 19
002 542 96 19
003 542 10 19
002 542 89 19
000 982 25 23
000 982 81 23
|
|
|
|
|
002 542 26 19
Multi-Function Relay #3 (4 pin) 2002-2018
Cube shaped 4 pin relay
Located under driver seat
|
|
|
|
|
004 545 79 05
Multi-Function Relay #5 2002 & LATERMercedes part # on unit could be 004 545 38 05 or 004 545 79 05
|
|
|
|
|
003 542 14 19
Multi-Function Relay (4 pin) SPRINTER & METRIS 2002-2018
Located under driver seat blue in color.
|
|
|
|
|
000 820 10 54
Rear Cargo Door Contact Switch 2002-2018
Found at the Rear door for overhead dome light.
|
|
|
|
|
906 545 19 13
Right Window Switch Assembly 2007-2018Right passenger door window switch
|
|
|
|
|
906 260 35 09
Shifter Control Assembly 2007-2018
The Neutral Safety Switch is part of this assembly and is not available as a separate unit.
THIS UNIT IS NOT PLUG AND PLAY. THE VEHICLE'S ECM MUST BE FLASHED (PROGRAMMED) USING THE CORRECT PROGRAMMING DEVICE, AT THE TIME OF INSTALLATION.
|
|
|
|
|
906 462 01 30
Steering Wheel Lock 2007-2018
Steering wheel lock also known as EVL or ESL.
This device locks the steering wheel for anti theft purposes. Found on steering column.
Genuine Mercedes part. |
|
|
|
|
906 827 01 39
Switch Hole Cover 2007-2018
Covers empty hole in instrument panel for those openings where no switch is used.
|
|
|
|
|
447 300 02 00
Throttle Pedal Actuator - 2007 & LATER
Complete assembly, with pedal.
For both METRIS and SPRINTER - 2007 & Later. |
|
|
|
|
002 540 94 17A
Tire Pressure Sensor - Replacement Type 2007-2012
One sensor is located at each wheel, including the spare tire.
For all vehicles equipped with TPMS.
This part is manufactured by VDO (315MHz) , the OEM supplier to Mercedes. It is a replacement unit and NOT the same as those sold at a franchise Mercedes, Dodge or Freightliner dealer. The frequency is identical and it will perform perfectly.
ORIGINAL UNIT IS ALSO AVAILABLE, SEE BELOW.
|
|
|
|
|
002 540 94 17 (SE58003)
Tire Pressure Sensor-Original Type 2007-2012
One sensor is located at each wheel, including the spare tire.
For all vehicles equipped with TPMS
This part is manufactured by VDO (315MHz), the OEM supplier to Mercedes.
It is identical to those sold at a franchise Mercedes, Dodge or Freightliner dealer.
|
|
|
|
|
000 905 72 00
Tire Pressure Sensor-Original Type 2013-2018
One sensor is located at each wheel, including the spare tire.
For all vehicles equipped with TPMS.
This part is manufactured by Schrader (433 MHz), the OEM supplier to Mercedes. It is identical to those sold at a franchise Mercedes, Dodge or Freightliner dealer.
|
|
|
|
|
906 545 02 10
Turn Signal Combi Switch With Rear Wiper 2007 & LATER
Turn signal and wiper switch on left side of steering column.
This switch is ONLY for models with wipers on the REAR CARGO DOORS, in addition to the front wipers.
|
|
|
|
|
906 545 03 10
Turn Signal Combi Switch WITHOUT Rear Wiper 2007 & LATER
Turn signal and wiper switch on left side of steering column.
This switch is ONLY for models without wipers on the rear cargo doors.
|
|
|
|
|
220 540 00 45
Washer Level Sensor 2007-2018
Washer reservoir level sensor in side of tank. See grommet below
|
|
|
|
|
002 546 79 40
Wiring Hub / Connector - Type A
These commonly will cause a "Can Bus" error.
Found throughout the vehicle, Mercedes calls it a "CABLE SHOE". Simply find the part
number on old part to verify this is the correct item you need.
|
|
|
|
|
005 546 10 40
Wiring Hub / Connector - Type B
These commonly will cause a "Can Bus" error.
Found throughout the vehicle, Mercedes calls it a "DISTRIBUTOR BLOCK". Simply find the part
number on old part to verify this is the correct item you need.
Has 5 x 2-pin plug connections and 1 x 3-pin plug connection.
|
|
|
|
|
004 546 82 40
Wiring Hub / Connector - Type C
These commonly will cause a "Can Bus" error.
Found throughout the vehicle, Mercedes calls it a "DISTRIBUTOR BLOCK". Simply find the part number on old part to verify this is the correct item you need.
|
|
|
