000 490 10 13
AdBlue DEF Injection Valve / Nozzle 2.1L 4 CYL Diesel 2014-2016
Only for the 4 CYL engines
Also known as DEF dosing valve.
This OEM Bosch manufactured valve is the identical part sold at a Mercedes dealer.
|
|
|
|
|
164 490 05 13
AdBlue DEF Injection Valve / Nozzle 3.0L V6 Diesel 2010-2018
aka DEF dosing valve
This OEM Bosch valve is the identical part as those sold at a Mercedes dealer.
|
|
|
|
|
000 995 11 33
AdBlue DEF Injection Valve / Nozzle Clamp
Clamp for Ad Blue Injection Nozzle (Diesel Emissions Fluid Injector Clamp)
|
|
|
|
|
906 470 05 53
AdBlue DEF Large Tank Heating Unit 2010-2014Check carefully before ordering this unit, as there are two versions of the DEF heating assembly, which also includes the level sender.
This unit is for the larger 25 Liter DEF tanks located UNDER THE VEHICLE, adjacent the exhaust system. Mercedes code MG5
The black cylinder on this unit is approximately 6 1/2 inches long. If the cylinder is 8 1/2 inches long, order the other unit shown below.
This is NOT for those vehicles with smaller 12 Liter AdBlue tank in the engine compartment.
|
|
|
|
|
906 470 03 53
AdBlue DEF Small Tank Heating Unit 2010-2014
The level sender is also part of this unit.
Only for the SMALLER 12 Liter AdBlue tank, located in the engine compartment (Code KP2)
The
black cylinder on this unit is approximately 8 1/2 inches long. If
the cylinder is 6 1/2 inches long, order the other unit shown below.
|
|
|
|
|
906 470 18 15-MB
AdBlue DEF Tank Assembly 2014-2016
MB Part# 906 470 18 15 - Verify part number before ordering.
See other part below, MB Part# 906 470 17 00
This unit is a complete unit with the tank heating unit, for models 2014 to 2016. This is the later version which must be replaced as a complete assembly, as it has a non-replaceable heating unit built in to the tank. If you look at the top of the tank, you can determine whether you have the sealed tank (this one) or the version with removable heating unit.
|
|
|
|
|
906 470 17 00
AdBlue DEF Tank Assembly 2016-2018
MB Part# 906 470 17 00 - Verify part number before ordering.
See other unit below with different MB Part# 906 470 18 15
This unit is a complete unit with the tank heating unit, for models 2016 and later. This is the later version which must be replaced as a complete assembly, as it has a non-replaceable heating unit built in to the tank.
|
|
|
|
|
906 470 17 05
AdBlue DEF Tank Cap 2010 & LATER
Cap for Diesel Emission Fluid tank (DEF/AdBlue)
This cap is located inside the engine compartment.
|
|
|
|
|
002 470 68 94 64
AdBlue DEF Tank Delivery Pump 2010-2014Pump for AdBlue urea emissions fluid.
If you have a later model 3.0L V6, compare your existing pump to the photo.
If it is not the same pump, see the one shown below for 2014 and later models. A change was made during model year 2014.
This pump is the identical original Bosch pump sold at a Mercedes dealer, and NOT the Chinese knock-off pump seen online.
aka as the DEF delivery or dosing pump
|
|
|
|
|
000 470 04 00
AdBlue DEF Tank Delivery Pump 2014 & LATER
This is for the later model vehicles, with the DEF tank labeled part number 906 470 18 15 on the top of the tank.
Pump for AdBlue urea emissions fluid and it is used for newer vehicles (All the 4 CYL and the later V6 engines). Also known as the DEF delivery or dosing pump. This pump is the identical original Bosch pump sold at a Mercedes dealer.
Compare your existing pump to the photo. A change was made during model year 2014. If not the same pump, see the earlier version pump as shown below.
|
|
|
|
|
642 016 02 81
Breather Hose 2007-2009From Crankcase Pressure Control Valve to Intake on 3.0 V6 engine
Oil vapor breather hose
|
|
|
|
|
642 094 05 80
Crankcase Vent Valve Heater Grommet 2004 & LATER
Grommet for two pin electrical sensor breather tube.
Or see below for the sensor with the grommet included.
|
|
|
|
|
906 470 22 64
DEF Feed Line 2010+ TYPE A
DEF Feed line to DEF injector, straight connection type.
There are two versions of this DEF line. They are not interchangeable.
Simply compare your existing line at the DEF injector connection to determine which one you need.
Notice the red circle with straight line connection.
The other version is shown below
|
|
|
|
|
906 470 16 00
DEF Feed Line 2010+ TYPE B
DEF Feed line to DEF injector, 90 degree type.
There are two different versions of this DEF line. They are not interchangeable. Simply compare your existing line at the DEF injector connection to determine which one you need.
Notice the red circle with 90 degree line connection.
|
|
|
|
|
906 490 06 00
Diesel Particulate Filter (DPF) 3.0L V6 Diesel 2010-2021
*** Currently Unavailable ***
Only for BlueTec engines, 2010 and later.
This unit is a combined device, consisting of Diesel oxidation catalyst up front and and a DPF in the rear of the housing.
This is a Brand New original Mercedes DPF, but it is sold as remanufactured/exchange. Your old unit must be returned for the core deposit refund.
|
|
|
|
|
906 490 15 92 80
Diesel Particulate Filter (DPF) 3.0L V6 Diesel 2007-2009
DPF for all 3.0 liter V6 turbo-diesels 2007 thru 2009 ONLY.
Not for BlueTec engines, 2010 and Later.
Clamps for each end of the DPF are available, shown below.
This is a Genuine Mercedes part.
|
|
|
|
|
906 490 00 42
DPF Band Clamp 3.0L V6 2010 & LATERInterfaces with the DPF bracket, shown below
|
|
|
|
|
906 492 12 00
DPF Bracket #1 2.1L 4 CYL 2014-2016
This DPF bracket is subject to cracking.
The old part number has been superseded twice by new revised part, which is a bit more robust.
This part is the most current revision.
|
|
|
|
|
906 492 08 42
DPF Bracket #2 2.1L 4 CYL 2014-2016
This DPF bracket is subject to cracking.
|
|
|
|
|
906 492 69 41
DPF Bracket 3.0L V6 2010 & LATER
This is the 3.0L V6 DPF bracket which is subject to cracking.
The old part number has been superseded by this new revised part, which is more robust.
This bracket interfaces with the DPF band clamp, shown below.
|
|
|
|
|
651 142 04 80
EGR By-Pass Tube Gasket 2.1L 4 CYL 2014-2016Flange gasket for EGR tube
|
|
|
|
|
002 540 70 97
EGR Change Over ValveElectro-Vacuum valve located in the EGR circuit on all Sprinter diesel engines.
On the V6, it is located behind passenger headlight. |
|
|
|
|
642 140 02 00
EGR Change Over Valve-Cooler End Housing 3.0l V6 2007 & LATERThis part is located at the back end of the EGR cooler.
The actual EGR valve is located at the front end of the EGR cooler. |
|
|
|
|
651 140 07 00
EGR Cooler 2.1L 4 CYL 2014-2016Heat exchanger/cooler for the EGR system
|
|
|
|
|
642 140 21 75
EGR Cooler 3.0 V6 Diesel 2007 & LATER
See all related gaskets, shown below |
|
|
|
|
642 142 01 81
EGR Cooler Gasket 3.0 V6 Diesel 2007 & LATER
|
|
|
|
|
651 203 18 82
EGR Cooler Hose 2014-2016 2.1L 4 CYL
|
|
|
|
|
642 141 04 83
EGR Cooler Hose A 2007 & LATEROnly for 3.0 V6 diesel |
|
|
|
|
642 141 05 83
EGR Cooler Hose B 2007 & LATEROnly for 3.0 V6 diesel |
|
|
|
|
651 142 24 80
EGR Cooler/By-Pass Valve Gasket 2.1L 4 CYL 2014-2016Located on end of the EGR cooler.
|
|
|
|
|
651 142 12 80
EGR Gasket 2.1L 4 CYL 2014-2016Gasket for EGR
|
|
|
|
|
651 140 22 08
EGR Pipe 2014-2016 2.1L 4 CYL
Adjacent to EGR Valve and Pressure Converter (Transducer)
|
|
|
|
|
651 142 26 80
EGR Pipe Gasket 2.1L 4 CYL 2014-2016This gasket is located on one end of the EGR pipe. |
|
|
|
|
651 142 03 80
EGR Pipe Gasket 2.1L 4 CYL 2014-2016This gasket is located between the exhaust manifold and the EGR pipe
|
|
|
|
|
642 142 18 80
EGR Pipe Gasket 3.0L V6 Diesel 2007 & LATERFits either end of stainless steel EGR pipes. See pipes pictured below.
|
|
|
|
|
642 140 21 08
EGR Pipe-LONG 3.0L V6 2010 & LATER
Stainless steel EGR pipe
|
|
|
|
|
642 140 09 08
EGR Pipe-SHORT 3.0L V6 2007 & LATER
Exhaust gas recirculation pipe. This is the shorter of the two pipes.
|
|
|
|
|
651 141 04 69
EGR Vacuum Actuator/Cell 2.1L 4 CYL 2014-2016Vacuum actuator for EGR system
|
|
|
|
|
651 140 08 60
EGR Valve 2.1L 4 CYL 2014-2016
New original EGR valve made by VDO, the OEM supplier to Mercedes and is the identical unit sold at a Mercedes dealer
This EGR is brand new and NOT remanufactured.
|
|
|
|
|
642 140 17 60-OEM
EGR Valve 3.0L V6 Diesel 2007-2009
*** Currently Out of Stock ***
For OM 642 Diesel Engine 2007-2009
BRAND NEW - No core deposit is required, sold outright.
Other than the gasket, no repair parts are available for this valve.
|
|
|
|
|
642 142 23 80
EGR Valve Gasket-3.0L V6 Diesel 2007 & LATERFor all 3.0L V6 EGR valves for 2007 and later
|
|
|
|
|
651 142 13 80
EGR Valve Gasket-A 2.1L 4 CYL 2014-2016The EGR valve on the 2.1L 4 CYL has two gaskets, A & B. See the other one (B), shown below. |
|
|
|
|
651 142 23 80
EGR Valve Gasket-B 2.1L 4 CYL 2014-2016The EGR valve on the 2.1L 4 CYL has two gaskets, A & B. See the other one (A), shown below.
|
|
|
|
|
642 141 02 83
EGR Valve Hose #1 2007 & LATEROnly for 3.0 V6 diesel
|
|
|
|
|
642 141 03 83
EGR Valve Hose #2 2007 & LATER
Only for 3.0 V6 diesel |
|
|
|
|
000 905 27 06
Exhaust Back Pressure Sensor 3.0L V6 2014 & LATER
See earlier version of this sensor below
|
|
|
|
|
007 153 43 28
Exhaust Back Pressure Sensor/Low Fuel Pressure Sensor 2002-2003 & 2007 & LATER 3.0L V6Located adjacent to EGR cooler on the 3.0L V6 models
Located on
left side of engine block on 2002-2003 5 CYL models (known as a low fuel pressure sensor)
Female plug, three contact pins inside plug housing.
|
|
|
|
|
906 995 02 02
Exhaust Clamp-70MM 3.0L V6 2010 & LATER
This clamp is for a 70MM OD tube
Located at output side of catalytic converter to tailpipe
|
|
|
|
|
642 140 14 60-MB
Genuine Mercedes - EGR Valve 3.0L V6 Diesel 2010 & LATER
Only for OM642 BluTec Diesel Engine (2010 and later)
Genuine Mercedes EGR Valve from the Benz Dealership.
Not for 2007-2009 models
|
|
|
|
|
004 989 04 20 14-MB
Genuine Mercedes - AdBlue DEF (Diesel Emissions Fluid) 2010 & Later
Genuine Mercedes Benz 10 Liter jug (approx. 2.6 gallons) bottle of DEF solution for the 2010+ V6 Bluetec diesels
|
|
|
|
|
