2007 & LATER Sprinter 3.0L V6 Serpentine Belt Kit ***FREE USA SHIPPING***
Rating: 0
Complete kit, as shown.  Tensioner is made by Litens, pulleys by INA and belt by ContiTech.  All three manufacturers are original equipment suppliers to Mercedes.

2-3 Day Shipping to any US Zip Code included!  Not valid for shipping outside the USA.

Do not order if you are NOT shipping to a USA address.

If you wish to ship outside the USA, please order all of the items in the kit individually.

$166.97

Belt Tensioner-Secondary 3.0 L Diesel Engine 2007-2010

Auxiliary A/C Belt Tensioner 3.0 L V6 Diesel Engine 2007 & LATER
Rating: 0
Only for OM642 diesel with rear A/C & 220 Amp Alternator
Includes damper/shock absorber

This is NOT the main serpentine belt tensioner.  This is only for those models equipped with
a second A/C compressor (roof air)

$89.00


Auxiliary Alternator Belt-3.0 L V6 Diesel Engine 2007 & LATER
Rating: 0
Only for 3.0 L V6 diesel

Only for models with an auxiliary alternator (two alternators). This belt will also drive the radiator fan.

If you have only the usual, single alternator, the fan drive belt for that is shown below.
$25.78

Fan Drive Pulley 3.0 L Diesel 2007-2014

Fan Drive Pulley 3.0 L Diesel 2007 & LATER
Rating: 0
1 required
Mounts to fan bearing bracket shown below
$20.97


Front Crankshaft Bolt 3.0L V6 2007 & LATER
Rating: 0
Located in center of crankshaft pulley.  Secures pulley to front of crankshaft.
$5.97

Crankshaft Seal FRONT 2002-2014

Front Crankshaft Seal 2.7L & 3.0 V6 2002 & LATER
Rating: 0
Fits all Sprinter 2.7L I-5 and V6 diesel engines
$9.97


Front Crankshaft Washer 2002 & LATER
Rating: 0
Located at front crankshaft pulley between the bolt and the pulley.
Used on all five cylinder and V6 engines
$7.73


Idler Pulley 2019+ Sprinter 2.0L 4 CYL & Metris 2016+
Rating: 0
Only one idler pulley is used for this engine.
Smooth faced pulley.

ONLY FOR 4 CYL GASOLINE ENGINES

$28.91


Idler Pulley Mounting Bolt 2002 & LATER
Rating: 0
Center bolt for idler pulleys.

Sold individually.  Two are required on most engines, possibly more on some models.

$2.93

Fan Drive Belt-Radiator  2007-2014

Radiator Fan Drive Belt 3.0L V6 2007 & LATER
Rating: 0
Drives only the radiator cooling fan and ONLY on those models that DO NOT have DUAL A/C
(Roof mounted A/C) with two A/C compressors.  If you have dual A/C, see the auxiliary belt shown below.


This is a very short belt compared to the main serpentine belt.  If you have an auxiliary alternator (two alternators),
that belt is shown below.
$16.93

Serpentine Belt Diesel Engine 2007-2014

Serpentine Belt 3.0L V6 Diesel 2007 & LATER
Rating: 0
Only for 3.0 Liter V6 diesel
This is the main serpentine belt.

Both the radiator fan drive belt (very short belt) and serpentine belt for those vehicles with auxiliary (roof mounted) A/C are shown below.
$27.91

Serpentine Belt Idler Pulley 2007-2014

Serpentine Belt Idler Pulley 3.0L V6 2007 & LATER
Rating: 5
(1)
Smooth surface, for 7PK belt

There are 2 of these pulleys required for the 3.0 L V6 diesel engine
$19.97


Serpentine Belt Tensioner 2.0L Sprinter 2019+
Rating: 0
Only for 4 CYL Gasoline engine Sprinter 2019+
$73.96

Belt Tensioner-Main 3.0 L Diesel 2007-2014

Serpentine Belt Tensioner-CODE B03 Main 3.0 L Diesel 2016+
Rating: 0
Only for 3.0 L V6 diesel engine, with CODE B03, which corresponds to vehicles equipped with ECO Direct Start.
This is an optional feature which shuts the engine off at idle, when stopped at a traffic light,  and automatically restarts the engine
when you step on the accelerator pedal.

This is a Litens belt tensioner and is the identical unit as those sold at a Dodge, Freightliner or Mercedes Benz dealer.
$98.52

Belt Tensioner-Main 3.0 L Diesel 2007-2014

Serpentine Belt Tensioner-Main 3.0 L Diesel 2007 & LATER
Rating: 0
Only for 3.0 L V6 diesel engine.

The ECO Direct Start engines (Code B03), use a different tensioner, which can be seen below.

This is a Litens belt tensioner and is the identical unit as those sold at a Dodge, Freightliner or Mercedes Benz dealer.
$99.88


Serpentine Belt-Sprinter 2.0L 2019 & METRIS 2016+
Rating: 0
A single serpentine belt is used on both the 2016+ Metris and 2019+ Sprinter 2.0L 4 CYL
$19.97


Woodruff Key for Crankshaft Pulley 2007 & LATER 3.0L V6
Rating: 0
Only for OM642 V6 3.0 L
$5.25
