000 989 33 09 11ABDW
5W30 1L - Genuine Mercedes 2002 AND LATER - 229.52
Genuine Mercedes Benz SAE 5W30 - MB SPEC 229.52
Sold in 1L bottles ONLY. |
|
|
|
|
000 989 63 08 11AAEW-MB
5W40 1L - Genuine Mercedes 2002-2006
Genuine Mercedes Benz SAE 5W40.
For T1N Sprinters 2002-2006
Genuine Oil is sold in 1L bottles ONLY.
|
|
|
|
|
910143-008006
Bolt M8 X 40MM
Also used as attachment screws (6 Required) for updated oil cooler / oil filter housing |
|
|
|
|
642 010 49 72
Engine Oil Dipstick 3.0L V6 Diesel 2007 & LATER
Note that this engine oil dipstick at one time was superseded from the original unit supplied from the vehicle. If your current dipstick measures 26.5 inches (End to End) then this will be a direct replacement. If not then the dipstick tube must be replaced at the same time, as the length of both has changed with the new update.
See the tube shown below... |
|
|
|
|
651 010 21 72-MB
Engine Oil Dipstick 4 Cyl Engine 2019+ Genuine Mercedes
This dipstick is not meant to be left inside the vehicle. |
|
|
|
|
112 016 00 00
Engine Oil Dipstick Grommet 2002 & LATER
Fits bottom of engine oil dipstick tube of all Sprinters.
Seals the dipstick tube to the engine block
Not for the transmission dipstick.
|
|
|
|
|
019 997 76 45
Engine Oil Dipstick O Ring 2002 & LATER
Fits top of engine oil dipstick of all Sprinters.
Seals the dipstick to dipstick tube.
Not for the transmission dipstick.
|
|
|
|
|
642 010 44 66
Engine Oil Dipstick Tube 3.0L V6 Diesel 2007-2022
Note that the original engine oil dipstick tube has been superseded to a new part number, as has the dipstick.
Replacement requires that both tube and dipstick be replaced at the same time.
See dipstick shown below. |
|
|
|
|
FUCHS 5W30-1L
Engine Oil FUCHS 5W30 1L - 2002 AND LATER - GT1 FLEX 23
Titan GT1 Flex 23 SAE 5W30 Engine Oil
Can be used in all Sprinters up to 2023
|
|
|
|
|
FUCHS 5W30-5L
Engine Oil FUCHS 5W30 5L - 2002 AND LATER - GT1 FLEX 23
Titan GT1 Flex 23 SAE 5W30 Engine Oil
Can be used in all Sprinters up to 2023
|
|
|
|
|
651 010 03 13
Engine Oil Pan 2.1L 4CYL - Aftermarket 2014-2016
Only for 2.1L 4 Cyl engines
See oil pan gasket shown below.
|
|
|
|
|
272 010 05 28
Engine Oil Pan 3.5L V6 Gas Engine 2007-2008Fits the 3.5 Liter V6 gasoline engine only
This pan is steel and painted black.
There is no gasket used for this oil pan. Use liquid sealant.
|
|
|
|
|
111 997 03 30
Engine Oil Pan Drain Plug 2002-2022 SPRINTER / METRIS 2016+
Fits all engine oil pans for 4 cylinder, 5 cylinder and V6 engines.
NOT FOR Sprinter III 2023+ 4 CYL diesel.
|
|
|
|
|
007603-014100-ALU
Engine Oil Pan Drain Plug Seal Ring 2002-2022 ALUMINUM
Aluminum Seal ring for oil pan drain plug.
Also used as a general seal ring with other parts such as sensors, etc.
|
|
|
|
|
007603-014100-COPPER
Engine Oil Pan Drain Plug Seal Ring 2002-2022 COPPER
Copper seal ring for oil pan drain plug.
|
|
|
|
|
651 010 01 69-MB
Genuine Mercedes - Oil Fill Tube 4 Cyl
Oil fill tube for 4 cylinder engines only. |
|
|
|
|
651 180 01 09-MB
Genuine Mercedes - Oil Filter 2.1L 4 Cyl Diesel 2014 & Later
Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine
The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.
Seal ring is not included with the filter.....see below. |
|
|
|
|
651 180 01 09-HENST X10
Hengst Oil Filter Kit 10 PACK 2.1L 4 CYL 2014 & Later
10 PACK - Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine
The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.
Seal ring is not included with the filter.....see below.
*Free USA Shipping*
|
|
|
|
|
LM2038
LIQUIMOLY 5W30 1L - 2002 AND LATER
1 Liter Container - SAE 5W30 Longtime High Tech Full Synthetic Motor Oil.
Made in Germany.
MB
Spec 229.51& 229.52 Low ash oil specified for all 2007 and later
models but is backward compatible for all 2002-2006 engines (229.3 &
229.5)
|
|
|
|
|
LM2039
LIQUIMOLY 5W30 5L - LM2039 - 2002 AND LATER
5 Liter Container - SAE 5W30 Longtime High Tech Full Synthetic Motor Oil.
Made in Germany.
MB
Spec 229.51 & 229.52 Low ash oil specified for all 2007 and later
models but is backward compatible for all 2002-2006 engines (229.3 &
229.5).
SHIPPED BY FEDEX GROUND. |
|
|
|
|
LM20446
LIQUIMOLY TOP TEC 4600 5W30 1L - 2002 AND LATER
1L Full Synthetic - Can be used in all Sprinters up to 2023
MB SPEC 229.52
Optimum for modern gasoline and diesel engines with multi-valve technology, Valvetronic and turbo charging. Especially suitable where there are long intervals between oil changes and heavy duty engine requirements. Also suitable for gas-powered vehicles (CNG/LPG). Tested safe with catalytic converters and turbo chargers. |
|
|
|
|
LM20448
LIQUIMOLY TOP TEC 4600 5W30 5L - 2002 AND LATER
5L Full Synthetic - Can be used in all Sprinters up to 2023
MB SPEC 229.52
Optimum for modern gasoline and diesel engines with multi-valve technology, Valvetronic and turbo charging. Especially suitable where there are long intervals between oil changes and heavy duty engine requirements. Also suitable for gas-powered vehicles (CNG/LPG). Tested safe with catalytic converters and turbo chargers. |
|
|
|
|
642 010 14 28
Lower Engine Oil Pan 2007 & LATER 3.0L V6
Fits the 3.0 Liter V6 diesel
This pan is cast aluminum, silver in color.
There is no gasket used for this oil pan. Use liquid sealant.
|
|
|
|
|
000000-001159
M6 X 20MM BOLT - ZINC PLATED TORX HEAD
M6 X 20MM
Sold Individually
Used on all SPRINTERS
|
|
|
|
|
910143-008017
M8 X 55MM BOLT - ZINC PLATED TORX HEAD
M8 X 55MM.
Sold individually.
Used on all SPRINTERS. |
|
|
|
|
651 180 01 09-MANN X10
Mann Oil Filter Kit 10 PACK 2.1L 4 CYL 2014 & Later
10 PACK - Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine
The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.
Seal ring is not included with the filter.....see below.
|
|
|
|
|
MOTUL 5W30-1L
MOTUL 5W30 1L 2002-2018
8100 X-clean EFE 5W30 1 liter container
MB Spec 229.52 |
|
|
|
|
MOTUL 5W30-5L
MOTUL 5W30 5L 2002 - 2018
8100 X-clean EFE 5W30 5 liter container
MB Spec 229.52
|
|
|
|
|
651 180 01 09-MAHLE
OEM Oil Filter - MAHLE 2.1L 4 Cyl Diesel 2014 & Later
OEM part - Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine
The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.
Seal ring is not included with the filter.....see below. |
|
|
|
|
642 180 01 65-MB
Oil Cooler 3.0L V6 Diesel - Genuine Mercedes 2007-2022
Genuine Mercedes part.
Engine oil cooler for all 3.0L V6 diesel engines.
SEE GASKET AND SEAL KIT BELOW FOR CHANGING THIS PART.
|
|
|
|
|
642 180 01 65-MAHLE
Oil Cooler 3.0L V6 Diesel - MAHLE 2007-2022
Engine oil cooler for all 3.0L V6 diesel engines.
SEE GASKET AND SEAL KIT BELOW FOR CHANGING THIS PART.
|
|
|
|
|
642 180 01 65-NISSENS
Oil Cooler 3.0L V6 Diesel - NISSENS 2007-2022
Engine oil cooler for all 3.0L V6 diesel engines.
SEE GASKET AND SEAL KIT BELOW FOR CHANGING THIS PART.
Manufactured in Denmark, by Nissens, one of Europe's largest and reliable radiator and cooling system component manufacturers. |
|
|
|
|
642 180 01 65-VEMO
Oil Cooler 3.0L V6 Diesel - VEMO 2007-2022
Engine oil cooler for all 3.0L V6 diesel engines.
SEE GASKET AND SEAL KIT BELOW FOR CHANGING THIS PART.
|
|
|
|
|
642 180 99 00
Oil Cooler Change Gasket / Seal Kit 2007 & LATER 3.0L V6 Diesel
All necessary seals and gaskets required to change out the engine oil cooler.
All items in this kit are a combination of Genuine Mercedes and OEM supplied gaskets from Elring and Reinz.
A few other gaskets and seal rings that you may want to consider changing are listed below. |
|
|
|
|
642 188 05 80
Oil Cooler Seal 3.0L V6 Diesel 2007-2022
2 of these seals are required for each engine.
Located between oil cooler and engine block - These are the newest, heat and leak resistant, purple Viton compound formulation, which replace the earlier orange seals.
DO NOT USE THE OLDER ORANGE COLORED SEALS IN THIS AREA, AS THEY ARE PRONE TO LEAKAGE.
|
|
|
|
|
000 010 16 85-MB
Oil Fill Cap - Genuine Mercedes SPRINTER 2002 & LATER + METRIS 2016+
Oil fill cap in valve cover or at end on extension tube on later V6 engines.
Genuine Mercedes part. |
|
|
|
|
000 010 16 85-AFT
Oil Fill Cap - SPRINTER 2002 & LATER + METRIS 2016+
Oil fill cap in valve cover or at end on extension tube on later V6 engines
|
|
|
|
|
642 010 81 07
Oil Fill Tube Extension 3.0L V6 2007-2022
Extension tube from engine to fill cap
|
|
|
|
|
651 180 01 09-HENGST
Oil Filter - HENGST 2.1L 4 Cyl Diesel 2014 & Later E11HD204
Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine
The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.
Seal ring is not included with the filter.....see below.
|
|
|
|
|
651 180 01 09-MANN
Oil Filter - MANN 2.1L 4 Cyl Diesel 2014 & Later
Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine
The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.
Seal ring is not included with the filter.....see below. |
|
|
|
|
651 180 13 10
Oil Filter / Oil Cooler Housing 2.1L 4CYL - Genuine Mercedes 2014-2017
The oil filter housing and the oil cooler are a combined unit on the 2.1L 4 CYL engine.
Neither of these two components is available as a separate unit.
See updated mounting screws for this unit below - Order a quantity of SIX. |
|
|
|
|
642 589 00 09 00
Oil Filter Cap Wrench - 3.0L V6 Diesel Engine 2007-2022
Only for 3.0L V6 OM642 turbodiesel engine.
All steel construction. This cap wrench has 14 flutes, as opposed to the incorrect ones with 15 flutes shown on many sites.
SERVICE TOOLS ARE NOT RETURNABLE. |
|
|
|
|
642 180 14 10
Oil Filter Housing Assy 3.0L V6 2007-2022
Oil Filter Housing Assembly |
|
|
|
|
642 180 00 38
Oil Filter Housing Cap - 3.0L V6 Diesel 2007-2022
Filter slides over end of spike. Holds O-rings that come with oil filter kit.
Only for 3.0L V6 diesel.
This cap often cracks when an incorrect
tool, such as channel-lock pliers are used to remove the cap, rather
than the special fluted tool designed to fit this cap. See the correct
tool listed below.
|
|
|
|
|
651 180 01 38
Oil Filter Housing Cap 2.1L 4CYL - Genuine Mercedes 2014-2017
Only for OM651 2.1L 4 CYL Diesel. |
|
|
|
|
642 184 00 80
Oil Filter Housing Flange Seal 3.0L V6 2007 & LATER
Located at flange between oil filter housing and engine block.
Mercedes does not offer a seal between the upper and lower sections of the oil filter housing.
If you are ordering a new oil filter housing (as shown below), you do not need to order this seal, as it is supplied with the new housing
|
|
|
|
|
651 014 00 28
Oil Pan Gasket 2014-2016 2.1L 4 CYLOil pan gasket only for the 2.1L 4 Cyl engine
|
|
|
|
|
651 180 13 01
Oil Pump 2.1L 4CYL 2014-2017
Engine oil pump for all 2.1L 4 CYL turbodiesel engines
This pump is manufactured by Pierburg, the OEM supplier to Mercedes. It is the same pump as sold at a franchise Mercedes dealer.
Same as Part Number: 651 180 14 00
|
|
|
|
|
642 180 16 00
Oil Pump 3.0L V6 2007 & LATER
Engine oil pump for all 3.0L V6 turbodiesel engines
|
|
|
|
|
003 997 74 94
Oil Pump Drive Chain 2002 & LATER
Oil pump drive chain for all 5 cylinder and V6 diesel engines.
Iwis is the OEM supplier for this part. |
|
|
|
|
642 181 00 80
Oil Pump Seal 3.0L V6 2007-2022
Seal between engine block and oil pump. |
|
|
|
|
642 010 19 91-MB
Oil Separator / PCV - Genuine Mercedes 2007-2009
Genuine Mercedes part.
Oil separator or PCV valve.
Not for BlueTec engines (2010 and later).
|
|
|
|
|
642 010 19 91-AFT
Oil Separator / PCV 2007-2009
Oil separator or PCV valve.
Not for BlueTec engines (2010 and later).
|
|
|
|
|
642 010 17 91-AFT
Oil Separator / PCV Assembly 2010-2022
Oil separator/PCV, breather hose and heating element, sold as a complete assembly
The heating element on this component, is a small but, very critical component, as it prevents the crankcase vapors from freezing. (water vapor is a byproduct of combustion) Oil and water emulsification forms when vapors come in contact with cooler temperatures, they freeze and the ice crystals can then easily erode the turbocharger intake blades. It does sound very strange but, it is true.
Only for BlueTec engines, which are 2010 and later. |
|
|
|
|
642 010 22 91-MB
Oil Separator / PCV Assembly 2007-2009
Oil separator / PCV valve, breather hose and heating element, together as an assembly - All three pieces are included in this assembly.
Not for BlueTec engines (2010 and later).
|
|
|
|
|
642 010 17 91-MB
Oil Separator / PCV Assembly 2010-2022
Oil separator/PCV, breather hose and heating element, sold as a complete assembly
The heating element on this component, is a small but, very critical component, as it prevents the crankcase vapors from freezing. (water vapor is a byproduct of combustion) Oil and water emulsification forms when vapors come in contact with cooler temperatures, they freeze and the ice crystals can then easily erode the turbocharger intake blades. It does sound very strange but, it is true.
Only for BlueTec engines, which are 2010 and later.
|
|
|
|
|
642 010 72 15
Oil Separator PCV Cover 3.0L V6 2007-2022
Oil separator / PCV - breather cover. |
|
|
|
|
651 010 16 82
PCV Breather Hose 2.1 4 CYL
Breather hose and heating element, sold as a complete assembly
The heating element on this component, is a small but, very critical component, as it prevents the crankcase vapors from freezing. (water vapor is a byproduct of combustion) Oil and water emulsification forms when vapors come in contact with cooler temperatures, they freeze and the ice crystals can then easily erode the turbocharger intake blades. |
|
|
|
|
642 096 01 00
Turbocharger Support Stand / Base 3.0L V6 2007-2022
This cast iron pedestal sits under the 3.0L V6 turbocharger, and houses the very critical turbocharger oil feed and drain lines.
This is the third revision of this part, replacing:
642 096 03 45
642 096 14 45
|
|
|
