SPRINTER GEN. II 2007-2018 (NCV3)

Engine Mechanical

Internal & External Engine Components

639 528 00 71 Air Filter Housing Screw V6 & 4 Cyl

For air filter housing cover, fits all V6 and 4 cylinder models.

$2.82

Idler Pulley & Bracket Assembly-3.0 L Diesel 2007-2014

642 200 06 70 Auxiliary Idler Pulley 3.0L V6 Diesel 2007-2022

This is just the pulley on the bracket and not the entire assembly.

This pulley is only used on those models that are equipped an auxiliary A/C system (second compressor).

It DOES NOT include the mounting bracket.

Pulley is smooth, 80mm in diameter and 26mm wide.

$15.50

642 091 01 50 Ball Socket 3.0L V6 Diesel 2007-2022

Ball socket insert for linkage to intake manifold inlet (swirl) actuator.

$3.84

642 050 09 16 KIT BASIC Timing Chain Kit-SPRINTER 3.0L V6 Diesel 2007-MID 2014

This 6-piece kit contains the timing chain and the four timing chain guides and the oil pump chain guide. All chain guides made in Germany by Febi-Bilstein and Iwis, the OEM suppliers to Mercedes. The original OEM Iwis, DOUBLE ROW, continuous timing chain is part of this kit.

The chain tensioner is not included but, it is available separately and also as part of the complete 7-piece kit, see below.

The oil pump drive chain is also not included but, it is also shown below.

$289.87

651 905 01 00 Camshaft Position Sensor 2014-2016 2.1L 4 Cyl

Only for OM651 4 Cyl engine

$41.88

651 052 00 00 Camshaft Timing Sprocket 2.1L 4CYL - Genuine Mercedes 2014-2017

Two are required for each engine. One on the end of each camshaft.

$94.71

642 090 59 37 Charge Air Intake Pipe 3.0L V6 2007-2022

Charge air intake line, upper end of this pipe joins the output side of the turbo resonator.

$134.84

651 050 00 16-KIT COMPLETE Timing Chain Kit 2.1L 4CYL - OEM 2014-2017

This 6-piece kit contains: (1) Timing Chain - with Master Link, (1) Timing Chain Tensioner, (1) Left Chain Guide Rail, (1) Right Chain Guide Rail, & (2) Camshaft Sprockets.

All parts made in Germany by IWIS, the OEM supplier to Mercedes for this part.

$319.71

642 050 00 16 KIT COMPLETE Timing Chain Kit-SPRINTER 3.0L V6 Diesel 2007-MID 2014

Complete 7-piece timing kit, consisting of the timing chain, DOUBLE ROW (continuous), timing chain tensioner and all four timing chain guide rails and the oil pump chain guide rail, for the 3.0L turbodiesel engine, from 2007 thru mid year 2014.

All parts made in Germany by Iwis, the OEM suppliers to Mercedes for these parts. See other kits and all timing other components, shown below.

$339.71

651 030 00 20 Connecting Rod 2.1L 4 Cyl 2014-2016

Only for OM651 2.1L 4 Cylinder engine

$378.91

642 030 52 20 Connecting Rod 3.0L V6 Diesel 2007-2009

Six required, sold individually.

Each connecting rod is complete with two bolts.

Previous part number: 642 030 41 20

$309.71

642 038 35 71 Connecting Rod Bolt 3.0L V6 Diesel 2007 & LATER

Twelve required (2 bolts per connecting rod), sold individually.

$6.97

Crankshaft Pulley/Vibration Damper 3.0 V6 2007-2014

642 030 06 03 Crankshaft Pulley / Vibration Damper 3.0 V6 2007 & LATER

Only for OM642 Turbodiesel engine, AKA HARMONIC BALANCER

Standard pulley/damper for models with or without roof A/C (Dual A/C compressors)

ALWAYS REPLACE THE CRANKSHAFT BOLT AT THE SAME TIME AS THE PULLEY

$249.71

651 030 08 03 Crankshaft Pulley/Vibration Damper 2.1L 4 CYL 2014-2016

Only for OM651 4 CYL Turbodiesel engine, AKA HARMONIC BALANCER

Standard pulley/damper for models without roof A/C (Dual A/C compressors)

ALWAYS REPLACE THE CRANKSHAFT BOLTS AT THE SAME TIME AS THE PULLEY

(4 ARE REQUIRED FOR THIS ENGINE)

$438.97

642 030 25 03 Crankshaft Pulley/Vibration Damper 3.0 V6-CODE B03 2010-2019

Only for OM642 Turbodiesel engine with code B03 AKA HARMONIC BALANCER

ALWAYS REPLACE THE CRANKSHAFT BOLT AT THE SAME TIME AS THE PULLEY

$287.92

273 030 03 03 Crankshaft Pulley/Vibration Damper-3.5l Gas Engine 2007-2008

Only for M273 Gasoline engine
NOT for OM642 Turbodiesel
aka as a HARMONIC BALANCER

$299.83

Timing Chain Tensioner-3.0L Diesel 2007-2014

642 050 08 03 Crankshaft Timing Chain Sprocket - 3.0L V6 Diesel 2007-2014

Crankshaft timing gear / sprocket for Sprinters with double roller chain

Only for OM 642 3.0L V6 turbodiesel engine

$169.91

Curil T2 CURIL T2 Sealing Compound-All Models

High temperature sealant for all types of engine sealing. Can be used with and without a gasket.

75 ml tube

Used for oil pans, front timing covers, valve covers, etc.

Any application where a seal is necessary where there is no fiber, rubber, nor metal gasket.

$9.71

651 010 55 11 Cylinder Head - New 2014-2016 2.1L 4 CYL

Only for 2014-2016 2.1L 4 CYL Engine

NEW Cylinder Head by A.M.C. (Made in Spain) with all valves, valve spring and valve guides, pre-installed. No camshafts.

Mercedes dealer sells this cylinder head with no valves, valve guides, springs, etc. & Dodge sells the head as a remanufactured unit.

$1,649.71

651 016 02 20 Cylinder Head Gasket 2014-2016 2.1L 4CYL

Head gasket alone, no other gaskets included

$69.71

642 010 18 20 Cylinder Head Gasket Set Sprinter 3.0L V6 2007 & LATER

Complete upper gasket set including both head gasket sets and all other gaskets and seals associated with both cylinder heads.

Manufactured by Elring, OEM gasket supplier to Mercedes for this part.

$236.65

000 997 62 20 Cylinder Head Plug - 30 MM 2007 & LATER 3.0L V6

Located on end of cylinder head

30 MM diameter or approx 1 and 3/16 inches

$4.84

000 997 63 20 Cylinder Head Plug 40MM 3.0L V6 - Genuine Mercedes 2007-2022

Located on end of cylinder head.

40 MM diameter or approx 1 and 9/16 inches.

$5.84

003 990 25 22 Cylinder Headbolt Set - 204mm 3.0L V6 Diesel 2007 & LATER

M8, 204mm (approx 8 inches long) cylinder head bolt, 8 per cylinder head. Order two sets if doing both heads.

Sold as a set of 8.

$42.71

642 010 08 67 Engine Cover 3.0L V6 2007 & LATER

Plastic cover on top of V6 Sprinter engine. Metal heat shield on the underside is included.

$245.71

642 094 07 85 Engine Cover Grommets - V6 and 4Cyl

Plastic engine cover grommets, fits the 3.0L V6 and the 2.1 4cyl engines

$5.00

Engine Mount-3.0 V6 Diesel Engine 2007-2014

906 241 17 13 Engine Mount 3.0L V6 Diesel 2007-2022

2 required, Fits both Left and Right side.

Sold in increments of 1.

Used only on 3.0L V6 turbodiesel engines.

$77.71

906 241 15 13 Engine Mount LEFT - 2.1L 4CYL - OEM 2014-2017

Left or Driver's side.

Left and Right mounts are different for this engine.

Used only on 2.1L 4 CYL turbodiesel engines.

$68.84

906 241 16 13 Engine Mount RIGHT - 2.1L 4CYL - OEM 2014-2017

Right side or Passenger's side mount

Left and Right mounts are different for this engine.

Used only on 2.1L 4 CYL turbodiesel engines

$94.71

906 241 11 13 Engine Mount-3.5 Liter Gas Engine 2007-2008

2 required
Sold in increments of 1
Used only on V6 gasoline engines

$69.91

651 010 03 13 Engine Oil Pan 2.1L 4CYL - Aftermarket 2014-2016

Only for 2.1L 4 Cyl engines

See oil pan gasket shown below.

$119.84

642 050 05 27 Exhaust Valve 3.0L V6 Diesel 2007-2022

Exhaust valve sold individually, 12 required for OM642 engine.

$17.71

642 030 05 12 Flex Plate/Ring Gear-3.0L V6 Diesel 2007 & LATER

Located between end of crankshaft & torque converter (bolts to face of torque converter)
AKA starter ring gear

$447.82

001 990 14 03 Front Crankshaft Bolt 2.1L 4 CYL 2014-2016

Located in center of crankshaft pulley. Secures pulley to front of crankshaft.

4 bolts are required for this engine

$6.47

000000-005724 Front Crankshaft Bolt 3.0L V6 2007-2022

Located in center of crankshaft pulley. Secures pulley to front of crankshaft.

$4.71

014 997 26 46 Front Crankshaft Seal 2.1L 4CYL 2014-2016

Only for OM651 4 CYL

$12.71

023 997 84 47-ELRING Front Crankshaft Seal 2.7L & 3.0L V6 2002 & LATER - Elring

Fits all Sprinter 2.7L I-5 and V6 diesel engines.

$12.84

023 997 84 47-MB Front Crankshaft Seal 2.7L & 3.0L V6 - Genuine Mercedes 2002-2022

Fits all Sprinter 2.7L I-5 and V6 diesel engines.

Genuine Mercedes part.

$19.71

604 990 00 40 Front Crankshaft Washer 2002-2022

Located at front crankshaft pulley between the bolt and the pulley.

Used on all five cylinder and V6 engines

$6.84

642 010 00 33 Front Timing Cover 2007 & LATER 3.0L V6 Diesel

Covers the front of the engine, houses the timing chain and guides. Includes the front crankshaft seal.

$248.91

651 010 01 69-MB Genuine Mercedes - Oil Fill Tube 4 Cyl

Oil fill tube for 4 cylinder engines only.

$44.71

651 050 00 80 Hydraulic Valve Lifter/Cam Follower 2.1 L 4 CYL 2014-2016

Cam follower or lifter
4 per cylinder or 16 total, per engine
Sold in increments of 1 each

$18.67

642 050 00 80 Hydraulic Valve Lifter/Cam Follower 3.0L V6 2007 & LATER

Cam follower or valve lifter
4 per cylinder or 24 total, per engine
Sold in increments of 1 each

$9.62

642 098 00 37 Intake Pipe Socket 3.0L V6 DIESEL - Genuine Mercedes 2007-2022

Furnished with both o-rings, which are not available as a separate item.

$9.69

Cylinder Head Gasket-LEFT 3.0 V6 Diesel 2007-2014

642 016 51 20 Left Cylinder Head Gasket 3.0L V6 Diesel 2007-2022

Head gasket for the Left or Driver's side cylinder bank.

$64.48

642 052 17 01 Left Exhaust Camshaft Sprocket-3.0L V6 Diesel 2007-2014

Only for OM 642 3.0L V6 turbodiesel engine

For double roller chain only.

Supersedes old sprocket 642 052 00 01

$114.84

642 052 19 01 Left Exhaust Camshaft Sprocket-3.0L V6 Diesel Mid 2014 & LATER

For SINGLE roller chain only.

Only for OM 642 3.0L V6 turbodiesel engine Mid 2014 and later

$116.88

642 010 14 28 Lower Engine Oil Pan 2007 & LATER 3.0L V6

Fits the 3.0 Liter V6 diesel

This pan is cast aluminum, silver in color.

There is no gasket used for this oil pan. Use liquid sealant.

$149.71

N 000000 001116 M6 X 19mm - Hexalobular Screw

Pressure line to Cylinder Head Cover, Return Pipe, Intake Manifold to Oil Pump, Oil level sensor to oil pan, Fuel Filter to Charge Air Distribution Line, Guide Tube to Cylinder Head and Oil Pan, Holder to Charge Air Distribution Line, and other areas.

$2.27

642 033 19 01-25mm O/S Main Bearing Set - 1ST RPR 75.75mm 3.0L V6 Diesel 2007 & LATER

1st Repair Size .25mm oversize OR 75.75mm, for undersize ground crankshaft.

Complete set of all four bearing shell pairs (8 shells in total).

These bearing sets are available in two sizes. Standard and first repair.

$189.77

642 033 19 01-STD SIZE Main Bearing Set - STD 76mm 3.0L V6 Diesel 2007 & LATER

Complete set of all four bearing shell pairs in STANDARD SIZE 76.00mm (8 shells in total).

These bearing sets are available in two sizes. Standard and first repair.

$166.00

642 011 02 71 MAIN CAP BOLT - 3.0L V6 Diesel 2007 & LATER

13 REQUIRED

$5.00

642 011 03 71 MAIN CAP BOLT - 3.0L V6 Diesel 2007 & LATER

3 REQUIRED

$7.48

910105-010011 MAIN CAP BOLT- 3.0L V6 Diesel 2007 & LATER

8 REQUIRED

$3.00

651 180 01 09-MAHLE OEM Oil Filter - MAHLE 2.1L 4 Cyl Diesel 2014 & Later

OEM part - Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine

The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.

Seal ring is not included with the filter.....see below.

$12.69

642 180 99 00 Oil Cooler Change Gasket / Seal Kit 2007 & LATER 3.0L V6 Diesel

(1)

All necessary seals and gaskets required to change out the engine oil cooler.

All items in this kit are a combination of Genuine Mercedes and OEM supplied gaskets from Elring and Reinz.

A few other gaskets and seal rings that you may want to consider changing are listed below.

$129.97

000 010 16 85-MB Oil Fill Cap - Genuine Mercedes SPRINTER 2002 & LATER + METRIS 2016+

Oil fill cap in valve cover or at end on extension tube on later V6 engines.

Genuine Mercedes part.

$11.84

000 010 16 85-AFT Oil Fill Cap - SPRINTER 2002 & LATER + METRIS 2016+

Oil fill cap in valve cover or at end on extension tube on later V6 engines

$8.71

651 180 01 09-HENGST Oil Filter - HENGST 2.1L 4Cyl Diesel 2014 & Later

Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine

The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.

Oil pan drain plug seal ring is not included with the filter.....see below.

$9.97

651 180 01 09-MANN Oil Filter - MANN 2.1L 4 Cyl Diesel 2014 & Later

Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine

The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.

Seal ring is not included with the filter.....see below.

$11.71

651 180 01 09-MB Oil Filter 2.1L 4Cyl - Genuine Mercedes 2014 & Later

Genuine Mercedes part.

Only for 2014 & Later, 2.1 Liter OM651 inline 4 cylinder diesel engine.

The OM651 2.1 liter 4 cylinder turbo engine oil capacity is 11.5 liters or 12.16 US quarts.

Seal ring is not included with the filter.....see below.

$17.71

651 180 01 38 Oil Filter Housing Cap 2.1L 4CYL - Genuine Mercedes 2014-2017

Only for OM651 2.1L 4 CYL Diesel.

$29.71

000 905 04 01 Oil Level Sender 3.0L V6 2007-2022 & 2.1L 4CYL 2014-2016

Located at oil pan, o-ring seal included

$139.71

102 014 00 33 Oil Pan End Plug 2002-2006

Located at rear end of engine oil pan

$3.97

651 014 00 28 Oil Pan Gasket 2014-2016 2.1L 4 CYL

Oil pan gasket only for the 2.1L 4 Cyl engine

$49.71

000 993 69 20 Oil Pump Chain Tensioning Spring 2007 & LATER 3.0L V6

Tensioning spring for oil pump drive chain slide rail

$6.34

642 181 00 80 Oil Pump Seal 3.0L V6 2007-2022

Seal between engine block and oil pump.

$3.84

642 030 12 17 54-.50mm O/S Piston - 1ST RPR 83.50mm, RIGHT SIDE 3.0L V6 2007 & LATER

1st repair size piston 83.50mm for 3.0L V6 Diesel engine, RIGHT CYLINDER BANK ONLY.

Furnished with rings, pin and pin retainer clips.

Sold individually, three required.

Also available in Standard size.....See below

$194.00

642 030 00 24 Piston Ring Set 3.0L V6 Diesel 2007 & LATER

Standard size (83.00mm bore) piston ring set for one piston. (Oversize rings are not available)

Sold as an individual set for one piston, six sets required per engine.

$47.71

642 030 13 18 54-.50mm O/S Piston-1ST RPR 83.50mm, LEFT SIDE 3.0L V6 2007 & LATER

1st repair size piston 83.50mm for 3.0L V6 Diesel engine, LEFT CYLINDER BANK ONLY.

Furnished with rings, pin and pin retainer clips.

Sold individually, three required.

Also available in Standard size.....See below.

$194.00

642 030 15 17 54-STD Piston-STANDARD 83.00mm, LEFT SIDE 3.0L V6 2007 & LATER

+++ CURRENTLY SOLD OUT +++

Standard size piston (83.00mm) for 3.0L V6 Diesel engine, LEFT CYLINDER BANK ONLY.
Furnished with rings, pin and 2 pin retainer clips. Sold individually, Three required.

Also available in 1st repair, .25 mm O/S - See Below.

642 030 12 17 54-STD Piston-STANDARD 83.00mm, RIGHT SIDE 3.0L V6 2007 & LATER

Standard size (83.00mm) piston for 3.0L V6 Diesel engine, RIGHT CYLINDER BANK ONLY.

Furnished with rings, pin and pin retainer clips. Sold individually, THREE required.

Also available is 1st repair, .25 mm O/S..... See below.

642 010 02 14 Rear Crankshaft Seal & Housing 3.0L V6 2007 & LATER

Rear crank seal, complete with housing.

This product is from Elring, an original equipment manufacturer for Mercedes.

The rear seal is also available by itself.....see below.

$39.69

014 997 25 46 Rear Crankshaft Seal 2.1L 4CYL 2014-2017

Only for OM651 4 CYL.

$14.53

642 010 02 14-SEAL Rear Crankshaft Seal 3.0 V6 2007 & LATER

Rear crank seal only, without housing.

Also available with the housing, see below.

$22.48

D 176 404 A2 REINZOSIL Sealing Compound - All Models

Reinzosil compound 70 ml tube

Used for engine oil pans (upper or lower), front timing covers, valve covers, front sealing flange, etc. Any application where a seal is necessary but, there is no fiber, rubber, nor metal gasket.

Resistant to mineral and synthetic oils, gasoline, diesel, lubricants, greases, sunlight, ozone, water, and seawater. (Anthracite Colored) Temperature Range: -50 deg. C to +250 deg. C (briefly to +300 deg. C)

$8.78

Cylinder Head Gasket-RIGHT 3.0 V6 Diesel 2007-2014

642 016 52 20 Right Cylinder Head Gasket 3.0L V6 Diesel 2007-2022

Contains head gasket for the Right or Passenger's side cylinder bank.

$64.48

642 052 18 01 Right Intake Camshaft Adjuster Sprocket-3.0L V6 Diesel 2007-2014

For double roller chain ONLY, 1 required

Supersedes old sprockets 611 052 05 01 and 646 050 01 49

Only for OM 642 3.0L V6 turbodiesel engine

$144.88

646 050 02 49 Right Intake Camshaft Sprocket-3.0L V6 Diesel 2007-2014

For double roller chain ONLY, 1 required

Supersedes old sprockets 611 052 05 01 and 646 050 01 49

Only for OM 642 3.0L V6 turbodiesel engine

$144.88

651 050 00 33 Rocker Arm 2.1L 4 CYL Diesel 2014-2016

Sold individually, 16 per engine

$14.88

642 050 01 33 Rocker Arm 3.0L V6 Diesel 2007 & LATER

Sold individually, 24 per engine

$12.88

642 030 02 60-.25mm O/S Rod Bearing Set - 1ST RPR 63.75mm 3.0L V6 Diesel 2007-2022

1st repair size (.25mm oversize or 63.75mm) for undersize ground crankshaft.

Complete set of all six pair of bearing shells (12 shells total).

Dealer sells these as individual pairs. We sell them in a complete set of six pairs.

These bearing sets are available in two sizes. Standard and first repair.

$211.93

642 030 02 60-STD SIZE Rod Bearing Set - STD 64mm 3.0L V6 Diesel 2007 & LATER

Standard size 64mm diameter.

Kolbenschmidt is the OEM supplier to Mercedes for this part.

Complete set of all six pair of bearing shells (12 shells total). Dealer sells these as individual pairs.

These bearing sets are available in two sizes. Standard and first repair.

$199.71

651 030 00 60 Rod Bearing Set-STD 2.1L 4 Cyl 2014-2016

Only for OM651 2.1L 4 Cylinder engine

$189.78

642 030 02 60-STD SIZE MB Rod Bearing Set-STD 64mm 3.0L V6 Diesel 2007 & LATER

Standard size 64mm diameter

Sold as one PAIR - For complete set, you need 6 PAIRS.

These bearing sets are available in two sizes. Standard and first repair.

$79.71

642 030 00 62 Thrust Bearing Set-STD 3.0L V6 Diesel 2007 & LATER

2.15mm/Standard

Look at main bearing cap 642 011 02 11 and remove the thrust bearing halves.

These are furnished as a set of both upper and lower halves (four bearing halves)

The photo only shows 50% of what you will receive.

The thrust bearings limit the horizontal forward & backward travel of the crankshaft

$52.97

000 993 63 76 C Timing Chain - DOUBLE ROW CONTINUOUS 3.0L V6 Diesel 2007-MID 2014

DOUBLE ROW timing chain for 3.0L V6 Diesel engines, thru mid year 2014.

This is a closed or continuous timing chain. There is no separable master link.

Replacing this chain requires removing the front timing cover.

$169.71

000 993 71 76 L Timing Chain - SINGLE ROW WITH LINK 3.0L V6 Diesel MID 2014-2022

SINGLE ROW TIMING CHAIN for later model 3.0L V6 Diesel engines.

This chain has a master link. See continuous chain version below.

IWIS is the OEM Supplier to Mercedes for this part.

$149.71

651 050 00 16 Timing Chain Clamping Rail-2.1L 4 Cyl Diesel 2014-2016

OM 651 2.1L turbodiesel engine
This is the larger of the two chain rails and it interfaces with the timing chain tensioner on the right side of the engine.

$15.88

Timing Chain Guide Kit-Diesel Engine 2007-2014

642 050 26 00 Timing Chain Guide Rail Kit - 3.0L V6 Diesel 2007-MID 2014

ONLY FOR ENGINES WITH DOUBLE ROW TIMING CHAIN, 2007 AND LATER, UP TO MID 2014

Set of all five chain guides are included in the kit. Four timing chain guides and one oil pump chain guide for 3.0L turbodiesel engine. None of these guides are available as separate pieces and only as this complete kit. See other components shown below.

All parts made in Germany by Febi-Bilstein, OEM supplier to Mercedes.

$99.69

642 050 27 00-FEBI Timing Chain Guide Rail Kit - 3.0L V6 Diesel MID 2014-2022

ONLY FOR ENGINES WITH SINGLE ROW TIMING CHAIN, MID 2014 AND LATER.

Set of all five chain guides are included in the kit. Four timing chain guides and one oil pump chain guide for the later 3.0L turbodiesel engine. None of these guides are available as separate pieces and only as this complete kit. See other components shown below.

All parts made in Germany by Febi-Bilstein, the OEM supplier to Mercedes.

$69.69
