901 410 87 06
2002 - 2003 Driveshaft Assembly This is a Genuine Mercedes Driveshaft Assembly from the Dealer.
Special Order Part Only - Contact Us with VIN number for proper fitment, accurate pricing and availability!
901 350 00 00
Differential Bearing Replacement Kit 2002-2006
Contains pinion shaft seal and all bearings for the differential, along with spacers, bolts, and gland nut.
Bearings will all be known brands, such as Timken, Koyo or SKF.
If your Sprinter is a late 2004, 2005 or 2006, nothing else will be required in this Kit, other than a cover gasket and replacement fluid.
If you have a 2002, 2003 or early 2004 model, then you will require a different spacer bushing and pinion shaft gland nut, See Below.
The spacer bushing in this Kit has the following dimensions:
Early models use a bushing with the following dimensions: (see these below)
Differential cover seal is NOT included but is available and shown below.
601 351 00 80
Differential Cover Seal 2002-2006 Seal between cover and differential housing.
001 989 28 03-FUCHS
Differential Fluid 80W90 2002-2006
Meets Mercedes Benz Spec Approval 235.0.
Order two of these one liter bottles, if doing a drain and replacement of your fluid for 2500 models.
Order three of these one liter bottles, if doing a drain and replacement of your fluid for 3500 models.
601 351 00 72
Differential Pinion Shaft Nut 2002-Early 2004
This nut needs to be ordered for those early T1N models which have a different nut and spacer bushing in the differential.
Also, see the different spacer bushing also, shown below.
601 351 01 72
Differential Pinion Shaft Nut 2004-2006
This nut for those Mid 2004-2006 T1N models. Picture is currently inaccurate, this nut has a taller collar.
108 353 00 42
Differential Spacer Bushing-32mm 2002-Early 2004
This bushing needs to be ordered for those early T1N models which have a different nut and spacer bushing in the differential.
This spacer bushing's dimensions are:
32mm ID and 16mm Length
Also, see the different pinion shaft nut, shown below.
903 410 00 10-FEBI
Driveshaft Support Assembly/Kit 2002-2006
Complete kit: Includes metal & rubber collar, boot, clamps, spacers, snap ring and the bearing in the center. AKA: Center Support
Two-piece driveshafts use just one support, three-piece driveshafts (long wheelbase models) require two supports, one front and one rear.
This Kit is manufactured by Febi Bilstein.
903 410 00 10-LEMFORDER
Driveshaft Support Assembly/Kit 2002-2006
Complete kit: Includes metal & rubber collar, boot, clamps, spacers, snap ring and the bearing in the center. AKA: Center Support
Two-piece driveshafts use just one support, three-piece driveshafts (long wheelbase models) require two supports, one front and one rear.
This Kit is manufactured by Lemfoerder, the OEM supplier to Daimler in Germany. It is identical to those sold at a franchise Dodge, Mercedes Benz or Freightliner dealer.
001 989 45 03 09-MB
Genuine Mercedes - 1L Transfer Case Fluid - 4x4
1 Liter Container - Genuine Mercedes
MB Spec 236.12 - for the 4x4 Sprinter Transfer Case Assembly
094 989 09 00 11-MB
Genuine Mercedes Benz - Differential Fluid 85W90 2002-2006
Mercedes Benz Spec 235.0
Order two of these one liter bottles, if doing a drain and replacement of your fluid for 2500 models.
Order three of these one liter bottles, if doing a drain and replacement of your fluid for 3500 models.
